Chapter 1 Cisco SRST SNMP MIB Support
The CISCO-SRST-MIB structure is further divided into the following groups:
SRST MIB Groups
ciscoSrstMIBNotifications
ciscoSrstMIBObjects
ciscoSrstMIBConformance
The CISCO-SRST-MIB structure further is divided into the following subgroups:
SRST MIB object groups
csrstConf
csrstNotifInfo
csrstSipConf
csrstActiveStats
csrstMIBNotifs
CISCO-SRST-MIB, which is uniquely identified by the number 441
Therefore the ciscoSrstMIB is1.3.6.1.4.1.9.9.441
Objects in the CISCO-SRST-MIB can be identified by either of the following methods.
The object identifier is 1.3.6.1.4.1.9.9.441<SRST MIB-variable>
•
The object name is iso(1).org(3).dod(6).internet(1).private(4).enterprise(1).cisco(9).ciscoMgmt(9)
•
.ciscoSrstMIB(441).<MIB-variable>
Figure 1-2
OL-7959-01
shows the position of the CISCO-SRST-MIB in the Internet MIB hierarchy.
