CISCO-SRST-MIB Object Groups
Table 1-6 SRST MIB Object Groups and Descriptions (continued)
MIB Group
csrstSipConfGroup
Cisco SRST SNMP MIB Release 3.4 Guide
1-40
MIB Object
csrstTotalUpTime
csrstSipRegSrvExpMax
csrstSipRegSrvExpMin
csrstSipIp2IpGlobalEnabled
csrstSipSend300MultSuppor
t
csrstSipVoRegPoolTag
csrstSipNetId
csrstSipVoRegPoolIpAddrTy
pe
csrstSipNetMask
csrstSipProxySrvIpAddr
csrstSipProxySrvPref
Max
Access Description
read-only Accumulated total number of minutes that router is
active in SRST mode.
read-only This object indicates the maximum expiration time for
the SIP Registrar Server to timeout on a registration.
read-only This object indicates the minimum expiration time for
the SIP Registrar Server to timeout on a registration.
read-only This object indicates whether voip calls are re-directed
IP to IP globally.
read-only This object indicates whether the redirect contact order
is best or longest match. This applies globally for SIP.
bestMatch (1),
longestMatch (2)
bestMatch - Uses the current system configuration to
set the order of contacts.
longestMatch - Sets the contact order by using the
destination pattern longest match first, and then the
second longest match, the third longest match, etc.
not-accessi A unique identifier tag configured for a voice register
ble pool entry.
read-only This object indicates the network identification
information of the SIP voice register pool configured
on this router. This object can be the network Id, IP
address, or MAC address.
read-only Internet address type governing the address type
format for one or more InetAddress objects in this
MIB. The associated InetAddress objects' description
will refer back to this type object as appropriate.
read-only This object indicates the IP subnet configured for the
SIP voice register pool. The type of IP subnet used here
is indicated by the csrstSipVoRegPoolIpAddrType
object.
read-only This object indicates the IP address of the proxy server
configured for the SIP voice register pool. The type of
IP address used here is indicated by the
csrstSipVoRegPoolIpAddrType object.
read-only This object indicates the preference order for creating
the VoIP dial peers in the voice register pool. Setting
the preference enables the desired dial peer to be
selected when multiple dial peers within a hunt group
are matched for a dial string. A value of 0 has the
highest preference.
Chapter 1 Cisco SRST SNMP MIB Support
OL-7959-01
