Summary of Contents for Briteq BT-60LS - V1.0
- Page 2 DANGER ~ GEVAAR ~ GEFAHR ~ PELIGRO ~ PERIGO WARNING: DANGER! never expose the lens to direct sunlight, even for a short period. This may damage the light effect or even cause fire! ATTENTION: DANGER! n'exposez jamais la lentille directement aux rayons de soleil, même pendant un bref instant.
-
Page 3: Before Use
ENGLISH OPERATION MANUAL ENGLISH OPERATION MANUAL SAFETY INSTRUCTIONS: OPERATION MANUAL CAUTION CAUTION: To reduce the risk of electric shock, do not remove the top cover. No user-serviceable parts inside. ® Refer servicing to qualified service personnel only. Thank you for buying this Briteq product. -
Page 4: Overhead Rigging
ENGLISH OPERATION MANUAL ENGLISH OPERATION MANUAL OVERHEAD RIGGING 3. BUTTONS MENU To select the programming functions Important: The installation must be carried out by qualified service personal only. Improper DOWN To go backward in the selected functions installation can result in serious injuries and/or damage to property. Overhead rigging requires To go forward in the selected functions extensive experience! Working load limits should be respected, certified installation materials ENTER... - Page 5 ENGLISH OPERATION MANUAL ENGLISH OPERATION MANUAL Show Mode Once the mode is selected, press the ENTER button to save it. Used to choose the Show mode when used in standalone or master/slave mode. To go back to the main menu without any change press the MENU button shortly. ...
-
Page 6: Electrical Installation + Addressing
ENGLISH OPERATION MANUAL ENGLISH OPERATION MANUAL Temperature inside the unit Electrical installation for two or more units in master/slave: Used to show the temperature inside the unit In this mode the units will show a synchronized show, working to the rhythm of the beat. ... - Page 7 ENGLISH OPERATION MANUAL ENGLISH OPERATION MANUAL DMX-Chart for 1MSL and 4MSL working modes DMX-CONFIGURATION OF BT-60LS: 1 MSL 4 MSL Electrical installation in DMX-mode: The DMX-protocol is a widely used high speed signal to control intelligent light equipment. You need to “daisy chain”...
-
Page 8: Maintenance
ENGLISH OPERATION MANUAL OPERATE THE UNIT BY CA8 OR RF8SET When used in standalone or master/slave mode we strongly advise you to use the CA-8 “Wired easy controller” or RF-8SET “Wireless easy controller”. CA-8 wired remote: Connect the controller to the jack input of the first unit (master). ...
