Network Designer - How To Set Interface Connection Parameters
Interface Connection Paramters
When you make certain physical Device-to-Device interface connections, a screen will appear asking you
to set the connection parameters. The following interface connections have parameters that can be set by
the user:
Frame Relay Connection
ISDN/PRI Connection
The parameters for these Devices do not need to be set by the user as they are loaded with default values.
However, if you wish to change these values and set the interface connection parameters yourself you can
do so during this step. Alternatively after the fact, you can:
1. Right click on the Frame Relay (not ISDN) icon in the NetMap Topology physical layout
window.
2. Click the Set Parameters option from the pop-up menu.
3. The Set Parameters window will appear.
4. After making changing parameters, click OK to close the window and return to the layout
window.
If you need to change the interface connection parameters for ISDN, please delete and re-create
the device in the NetMap Topology physical layout window.
Note: For additional information on PRI please see the "sequential labs".
© 2004 Boson Software, Inc. All Rights Reserved.
62
