Physical and Logical Density Maximums

Table 9 lists physical and logical density maximums for the E120 router and the
E320 router. The following notes are referred to in Table 9:
1. Wire rate indicates the port density that supports maximum (wire-rate)
2. With a 120 Gbps configuration on the E120 router, you can install up to 6
Table 9: Physical and Logical Density Maximums
Feature
Physical density wire rate/oversubscribed
(See Note 1 on page 91.)
10-Gigabit Ethernet ports per chassis
(ES2-S1 10GE IOA)
10-Gigabit Ethernet ports per chassis
(ES2-S2 10GE PR IOA)
(See Note 2 on page 91.)
Gigabit Ethernet ports per chassis
(ES2-S1 GE-4 IOAs)
Gigabit Ethernet ports per chassis
(ES2-S1 GE-8 IOAs)
(See Note 2 on page 91.)
Gigabit Ethernet ports per chassis
(ES2-S3 GE-20 IOA)
(See Note 2 on page 91.)
OC3/STM-1 ATM ports per chassis
(ES2-S1 OC3-8 STM1 ATM IOAs)
OC12/STM-4 ATM ports per chassis
(ES2-S1 OC12-2 STM4 ATM IOAs)
performance. Oversubscribed indicates the port density possible if you are
willing to accept less than wire-rate performance by oversubscribing the
available fabric bandwidth.
combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in
slots numbered 0-5. You can install a maximum of 6 active ports and 6
redundant ports at any time.
With a 100 Gbps fabric configuration on the E320 router, you must install the
ES2 10G Uplink LM, the ES2 10G LM, or the ES2 10G ADV LM in either of the
E320 router turbo slots (2 and 4). When the ES2 10G Uplink LM, the ES2 10G
LM, or the ES2 10G ADV LM is installed in slot 2 or slot 4, you cannot install
another line module in slot 3 or slot 5. In this case, you can only install the ES2
4G LM in slots 0–1 and 6–11; therefore, the maximum number of ports and the
forwarding performance per chassis is reduced for the IOAs that pair with the
ES2 4G LM.
With a 320 Gbps fabric configuration on the E320 router, you can install up to
12 combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in
slots numbered 0-5 and 11-16. You can install a maximum of 12 active ports
and 12 redundant ports at any time.
E120
6
6 + 6
24
96
120
96
24
Appendix A: System Maximums
E320
12
12 + 12
48
192
240
192
48
E120 and E320 System Maximums
91
