- Page 1 HPE Aruba Networking 500R Series Remote Access Points Installation Guide...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
- Page 3 Electrical Environmental Regulatory Information Safety and Regulatory Compliance Brazil Canada EU and UK Regulatory Conformity European Union and United Kingdom México Нормативные требования Евhразийского Экономического Союза Ukraine Taiwan UKCA United States Medical HPE Aruba Networking 500R Series Remote Access Points...
- Page 4 About This Guide About This Guide This document describes the hardware features of the HPE Aruba Networking 500R Series Remote Access Points. It provides a detailed overview of the physical and performance characteristics of each access point model and explains how to install the access point.
- Page 5 Chapter 2 Hardware Overview Hardware Overview The HPE Aruba Networking 500R Series access points are dual-radio 802.11ax Wi-Fi 6 remote access points that provide connectivity for both wired and wireless client devices. Package Contents The following materials are included with this product: AP-503R Access Point AC-to-DC Power Adapter with Country-Specific AC Power Plug...
- Page 6 Figure 2 AP-503R Rear and Side View Primary DC Power Port (Circular) Alternate DC Power Port (USB-C) E0 Ethernet Port (Uplink) E1 Ethernet Port (Downlink) E2 Ethernet Port (Downlink) USB Type-A Host Port Kensington Lock Slot HPE Aruba Networking 500R Series Remote Access Points |...
- Page 7 Table 2: System Status LED Color/State Meaning Access point powered off Green - blinking Access point booting, not ready Green - solid Access point ready, fully functional System error condition - Immediate attention required HPE Aruba Networking 500R Series Remote Access Points...
- Page 8 After inserting the L-shape DC connector of the power adapter into the DC power port, rotate the DC connector by 90 degrees and route the power cord through the cable hook on the access point. See Figure 4 Figure HPE Aruba Networking 500R Series Remote Access Points |...
- Page 9 Figure 5 Routing Power Cord through Cable Hook Alternate DC Power Port (USB-C) The USB-C port is designed to offer an alternate way to provide DC power to the AP-503R access point by using a compatible 5V/3A USB-C power adapter. HPE Aruba Networking 500R Series Remote Access Points...
- Page 10 Link established at reduced speed (100Mbps) USB Type-A Host Port The USB Type-A host port supports the HPE Aruba Networking MDM-USB-LTE modem, HPE Aruba Networking AP-USB-ZB IOT radio module and other compatible peripherals. When active, this USB port can supply up to 5W/1A to a connected device.
- Page 11 1. Connect the console port on the access point to the serial port on the computer using the proprietary HPE Aruba Networking AP-CBL-SERU cable or AP-MOD-SERU module, which need to be purchased separately. 2. Start the terminal emulation software on the computer and configure a new serial session with the...
- Page 12 Access Point Installation Access Point Installation All HPE Aruba Networking access points should be professionally installed by a professional installer. The installer is responsible for meeting applicable national and electrical codes. Failure to properly install this product may result in physical injury and/or damage to property.
- Page 13 FCC grant of equipment authorization. Any such willful or intentional violation may result in a requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80). HPE Aruba Networking 500R Series Remote Access Points...
- Page 14 Kingdom's Radio Equipment Regulations 2017/UK is available for viewing below. Select the document that corresponds to your device’s model number as it is indicated on the product label. EU & UK Declaration of Conformity Compliance is only assured if the HPE Aruba Networking approved accessories as listed in the ordering guide are used. https://www.arubanetworks.com.
- Page 15 HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г. Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677 'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г. Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Телефон/факс: + 7 727 355 35 50...
- Page 16 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against HPE Aruba Networking 500R Series Remote Access Points |...
- Page 17 3. Wipe with a dry cloth, no additional maintenance required. 4. No serviceable parts, the unit must be sent back to the manufacturer for repair. 5. No modifications are allowed without HPE Aruba Networking approval. HPE Aruba Networking 500R Series Remote Access Points...
