USER INSTRUCTIONS
5K ZINC PLATED SWIVEL ANCHOR
Complies with ANSI Z359.18 Type A,
OSHA 29 CFR 1910 and 1926 regulations.
OPERATION AND INSTRUCTION MANUAL
Models: A320011, A320013, A320014, A321013,
Page 1
Swivel Anchor
A360000, A510011, A510012
WARNING:
UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE
FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL USERS OF THIS PRODUCT MUST BE PROPERLY
INSTRUCTED ON HOW TO USE THE DEVICE. AVOID CONTACT
WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL, ELECTRICAL,
ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
FALL PROTECTION
ALL USERS OF THIS EQUIPMENT MUST READ AND
Advertisement
Related Manuals for Werner A320011
Summary of Contents for Werner A320011
- Page 1 Complies with ANSI Z359.18 Type A, OSHA 29 CFR 1910 and 1926 regulations. OPERATION AND INSTRUCTION MANUAL Swivel Anchor Models: A320011, A320013, A320014, A321013, A360000, A510011, A510012 WARNING: ALL USERS OF THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH.
- Page 2 User Instructions must always be available to the user and are not to be removed except by the user of this equipment. For proper use, see supervisor, User Instructions, or contact the manufacturer. Werner Co. can supply additional information upon request.
- Page 3 LABEL LOCATIONS 180˚ 2.25 inches ø (57.15mm) 8 inches ø (203.2mm) 5.5 inches (139.7mm) 360˚ 3 inches (76.2mm) Tensile Strength (UTS): 5,000-lbf (22kN) Weight: 1.2-lbs (544.3g) Materials: Zinc Plated Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7-2019 OSHA 29 CFR 1926.502, OSHA 29 CFR 1910.140 LOADING CONDITIONS DIAGRAM LOAD...
- Page 4 - Concrete strength must be at least 3000psi (20.7MPa) and no less than 7 inches (178mm) thick. Torque Range: 40 ft-lbs (54Nm) 7 inch (178mm) STEEL MOUNTING MODELS: A320011 & A320014 .5 inch -13 inch Lock Nut Torque : 45 ft-lbs (61 Nm) .5 inch tapered Lock Washer washer .5 inch -13 x 4 inches...
- Page 5 JOIST MOUNTING MODEL: A321013 .5 inch -13 inch Lock Nut .5 inch Lock Washer Channel Plate Joist members must meet anchorage requirements 4 inch steel Assembled Views Joist Spacer Swivel Anchor .5 inch -13 x 4.5 inches Hex Bolt Torque : 45 ft-lbs (61 Nm) 2.1 inches...
- Page 6 PART NUMBER KIT CONTENTS A320013 (Anchor Swivel 5K) A320011 (Steel Mounting Hardware Kit) A320014 (Swivel with Steel Mounting kit) A321013 (Joist Mounting Kit) A510012 (Concrete Hardware Kit) A510011 (Swivel with Concrete Mounting Kit) Page 6...
- Page 7 MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
- Page 8 Werner Co. 555 Pierce Road, Suite 300 Itasca, IL 60143 1(888) 523-3371 toll free 1(888) 456-8459 fax Page 8 P/N 109313-01 REV D...
