USER INSTRUCTIONS
VERTICAL / FIXED BEAM CLAMP
Complies with ANSI Z359.18 Type A,
OSHA 1910 and 1926 requirements.
ADJUSTABLE FROM 4"-14" (.10m - .36m)
FALL PROTECTION
I-BEAM ANCHOR
Model # A460000
WARNING:
ALL USERS OF THIS EQUIPMENT MUST READ AND
UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE
FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL USERS OF THIS PRODUCT MUST BE PROPERLY
INSTRUCTED ON HOW TO USE THE DEVICE. AVOID CONTACT
WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL, ELECTRICAL,
ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A460000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Werner A460000

  • Page 1 Complies with ANSI Z359.18 Type A, OSHA 1910 and 1926 requirements. I-BEAM ANCHOR ADJUSTABLE FROM 4”-14” (.10m - .36m) Model # A460000 WARNING: ALL USERS OF THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
  • Page 2: Use Instructions

    PURPOSE The A460000 is an anchorage connector designed to function as an interface between the anchorage and a fall arrest, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector” in this manual include, and apply to, the A460000.
  • Page 3: Label Locations

    PERFORMANCE: REGULATORY COMPLIANCE: ANSI Z359.18 Type A Minimum Breaking Strength (MBS): 5000-lbf (22kN) Maximum Capacity: one worker when used ANSI Z359.7-2019 as a single point anchorage connector for OSHA 1926.502 personal fall arrest or restraint system. OSHA 1910.140 DIMENSIONS: COMPONENT MATERIALS: Weight: 6.8-lbs Zinc Plated Steel Beam Flange Width Range: 4 inches-14 inches...
  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS 1. Press lock button and slide adjustable paw to widest position. 2. Fully loosen nut by turning counterclockwise. 3. Hook fixed paw on far side of I-beam flange. 4. Press lock button and slide adjustable paw to tightest notch to capture I-beam flange.
  • Page 5 5. Pull back on adjustable paw to ensure it is in a locked position. 6. Hand tighten nut as much as posible by turning clockwise. 7. Use lever to tighten an extra 1/4 turn. Refer to “NUT POSITONS” diagram to ensure correct installation. If nut position is incorrect, repeat all steps ensuring lock button engages in tightest position during step 4.
  • Page 6 * SHOCK ABSORBING DEVICE * REQUIRED ABOVE ANCHOR POINT (ANCHOR POINT) WORK SURFACE WORK SURFACE *Free fall distance (limit) must not exceed 6 feet (1.8m). *All products subjected to fall arresting forces should be removed from service immediately! MINIMUM CLEARANCE 2 feet (.6m) DECK/FLOOR/GROUND LEVEL...
  • Page 7: Maintenance, Cleaning And Storage

    MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. Frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
  • Page 8 Werner Co. Corporate Headquarters: 555 Pierce Rd, Suite 300, Itasca, IL 60143 888-523-3371 Toll Free • 888-456-8459 Fax P/N 108209-02 REV F...
