Werner A330000 User Instruction Manual

D-Ring Anchorage Connector
WARNING:
Compliant fall protection equipment must
only be used as it was designed. Users MUST read and understand
all user instructions provided with the product. Before using a
fall arrest system, users must be trained in the safe use of the
system, as required by OSHA 29 CFR 1910.30 and 1926.503, or local
safety regulations. Misuse or failure to heed these warnings and
instructions may result in injury or even death.
WORK SAFE! WORK SMART!
I
MPORTANT
Before use, the user must read and understand these User Instructions.
Keep these User Instructions for reference.
P
URPOSE
WernerCo D-Ring Anchorage Connectors are designed to function as an
interface between the anchorage and travel restraint, work positioning, fall
arrest, or rescue system.
U I
SE NSTRUCTIONS
1. Failure to follow all instructions and limitations on the use of the
D-Ring Anchorage Connector may result in serious personal injury or
death.
2. Before using a personal fall arrest system, employees must be trained
in accordance with the requirements of OSHA 29 CFR 1910.30 and
1926.503 in the safe use of the system and its components.
3. Personal fall arrest and rescue systems, including the D-Ring
Anchorage Connector, must be inspected prior to each use for
wear, damage, and other deterioration. Defective components
must be immediately removed from service in accordance with the
requirements of OSHA 29 CFR 1910.140 and 1926.502.
4. The complete fall arrest system must be planned (including all
components, calculating fall clearance, and swing fall) before using.
5. Users must have a rescue plan, and the means at hand to implement
it, that provides for the prompt rescue of the user in the event of a fall,
or assures that the user is able to rescue themselves. A fall over an
edge may require special rescue measures.
6. Store the D-Ring Anchorage Connector in a cool, dry, clean
environment, out of direct sunlight, when not in use.
7. After a fall occurs on the system, immediately remove from service
until a "competent person" can make the determination for reuse or
disposal.
U L
SE IMITATIONS
D-Ring Anchorage Connectors have been tested in compliance with the
requirements of ANSI/ASSE Z359.7. Compliance and testing covers only
the hardware and does not extend to the anchorage and substrate to
which the D-Ring Anchorage Connector is attached.
1. ANCHORAGE: D-Ring Anchorage Connectors must only be used
on structures capable of supporting loads applied in all directions
permitted by the fall arrest system of at least: 3,600 pounds (16.0 kN)
with certi cation of a quali ed person, or 5,000 pounds (22.2 kN)
without certi cation.
2. SUBSTRATE: D-Ring Anchorage Connectors must only be used on
steel with a minimum thickness of ¼ inch (6.4 mm).
Model No. Material
Alloy Steel;
A330000
Stainless Steel
User Instruction Manual
Length Width Connection Size
6 in 3 in
(154 mm) (80 mm) (61 mm)
A330000
3. FASTENERS: Only use Grade 5 or stronger
head bolts and nuts (sold separately).
4. LOADING: D-Ring Anchorage Connectors are permitted to be loaded
in all directions.
5. CONNECTION: Only one travel restraint, work positioning, fall arrest,
or rescue system may be attached to an individual connect point.
6. EXTREME TEMPERATURE: D-Ring Anchorage Connectors are
designed to be used in temperatures ranging from -40°F to +130°F
(-40°C to +54°C). Protection should be provided when used near
welding, metal cutting or similar activities. Contact WernerCo with any
questions concerning high temperature environments.
7. ELECTRICAL HAZARDS: Use extreme caution when working near
high voltage power lines due to the possibility of electric current
owing through the D-Ring Anchorage Connector or connecting
components.
8. HEALTH: Minors, pregnant women and anyone with a history of either
back or neck problems should not use this equipment.
9. RESCUE: In the event of a fall over the edge, special rescue
measures may be required.
10. TRAINING: Do not use D-Ring Anchorage Connectors without proper
training from a "competent person" as de ned by OSHA 29 CFR
1910.140(b) and 1926.32(f).
11. REPAIRS: Only WernerCo, or persons or entities authorized in writing
by WernerCo, may make repairs or alterations to the equipment.
C L
OMPATIBILITY IMITATIONS
All connecting subsystems must only be coupled to compatible connectors.
OSHA 29 CFR 1910.140 and 1926.502 prohibit snap hooks from being
engaged to certain objects unless two requirements are met: snap
hook must be a locking type and must be "designed for" making such a
connection. Under OSHA "designed for" means that the manufacturer of
the snap hook speci cally designed the snap hook to be used to connect
to the equipment in question.
The following connections must be avoided because they can result in
rollout* when a non-locking snap hook is used:
• Direct connection of a snap hook to horizontal lifeline.
• Two (or more) snap hooks connected to one D-ring.
• Two snap hooks connected to each other.
• A snap hook connected back on its integral lanyard.
• A snap hook connected to a webbing loop or webbing lanyard.
• Improper dimensions of the D-ring, rebar, or other connection point in
relation to the snap hook dimensions that would allow the snap hook
keeper to be depressed by a turning motion of the snap hook.
*Rollout: A process by which a snap hook or carabiner unintentionally
disengages from another connector or object to which it is coupled.
I
NSTALLATION
Drill a inch hole where needed in the anchorage structure. Attach the
D-Ring Anchorage Connector using a
bolt and nut. Torque bolt to 100-150 ft-lbs.
Hole Diameter
2 in 5/8 in
(17 mm)
inch - 11 steel hex
inch - 11 Grade 5 steel hex head
Weight MBS Compliance Standards
9.5 oz 5,000 lbs ANSI Z359.18-2017 Type A
(268 g) (22.2 kN) OSHA 1910 & 1926
