Werner EASY SLIDER A550030 Instruction Manual

I-beam anchor adjustable from 12- 30 inches .30m - .76m
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

EASY SLIDER
I-BEAM ANCHOR
ADJUSTABLE FROM 12- 30 inches (.30m - .76m)
Model # A550030
WARNING:
ALL USERS OF THIS EQUIPMENT MUST READ AND
UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE
FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL USERS OF THIS PRODUCT MUST BE PROPERLY
INSTRUCTED ON HOW TO USE THE DEVICE. AVOID CONTACT
WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL, ELECTRICAL,
ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 8,312,966 B1 / US 8,646,575 B1
V2.6-F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EASY SLIDER A550030 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Werner EASY SLIDER A550030

Summary of Contents for Werner EASY SLIDER A550030

  • Page 1 EASY SLIDER I-BEAM ANCHOR ADJUSTABLE FROM 12- 30 inches (.30m - .76m) Model # A550030 WARNING: ALL USERS OF THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.

  • Page 2: Use Instructions

    User Instructions must always be available to the user and are not to be removed except by the user of this equipment. For proper use, see supervisor, User Instructions, or contact the manufacturer. Werner Co. can supply additional information upon request.

  • Page 3: Component Materials

    PERFORMANCE: REGULATORY COMPLIANCE: Minimum Breaking Strength (MBS): ANSI Z359.18 Type A, ANSI Z359.7-2019, 5000-lbf (22kN) OSHA 1926.502, OSHA 1910.140 Maximum Capacity: One worker when used as a single point anchorage connector COMPONENT MATERIALS: for personal fall arrest or restraint system Aluminum: Cross Bar DIMENSIONS: Bronze: Clamps...
  • Page 4 LOADING CONDITIONS DIAGRAM Placement at or below a user’s working height requires integration of a compatible ANSI Z359.1 shock-absorbing lanyard that does not allow the user to extend more than 6 feet (in any direction) from the anchorage connector before the shock absorber is activated. The beam anchor must be attached to the I-beam flange facing the user (top flange if above, bottom flange if below, etc.).
  • Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 1800-lbf (8 kN). (ANCHOR POINT) WORK SURFACE Inspect retaining bushing for wear or damage.

  • Page 6: Warning Label Locations

    WARNING LABEL LOCATIONS BREAKING STRENGTH: 5000 lbf (22.2 kN) MFG: MM/YYYY WARNING: All persons using this equipment must read, understand and follow all instructions. Failure to do so could result in serious injury or death. Compliance: OSHA 1926.502 & 1910.140, ANSI Z359.18 Type A ANSI Z359.7(19) WARNING: ALL USERS OF THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS.

  • Page 7: Maintenance, Cleaning And Storage

    MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
  • Page 8 Werner Co. 93 Werner Road Greenville, PA 16125 1(888) 523-3371 / www.wernerco.com P/N 105548-02 REV F 5/21...
