LPS (Local Positioning System) Module User Manual
Part Number: LBES0ZZ1VG
LBES0ZZ1VG has been FCC/ISED certified as Single Modular Approval with the following IDs.
FCC ID: VPYLB1VG
The module is limited to OEM installation ONLY. The OEM integrator is responsible for ensuring that the end-user
has no manual instruction to remove or install module.
Therefore, the final host product must be submitted to Murata for confirmation that the installation for the
module into the host is in compliance with regulations of FCC and IC Canada. Specially, if an antenna other than
the model documented in the Filing is used, a Class 2 Permissive Change must be filed with the FCC.
Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate
the equipment.
This module has been approved by FCC to operate with the antenna types with the maximum permissible gain
indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device. The following antennas have been certified in combination
with the module. Refer to next pages for the antenna application guidance.
(a) Dipole whip antenna ANT-DB1-RAF-RPS for WLAN with peak gains of 4.1dBi (2.4GHz) and 5.1dBi (5GHz);
(b) Monopole PCB antenna for 5GHz WLAN with peak gain of 4.5dBi;
(c) Monopole PCB antenna for Sub-GHz with a peak gain of 1.5dBi;
IC: 772C-LB1VG
Advertisement
Related Manuals for Murata LBES0ZZ1VG
Summary of Contents for Murata LBES0ZZ1VG
- Page 1 Therefore, the final host product must be submitted to Murata for confirmation that the installation for the module into the host is in compliance with regulations of FCC and IC Canada. Specially, if an antenna other than the model documented in the Filing is used, a Class 2 Permissive Change must be filed with the FCC.
- Page 2 Antenna Application Guidance There is no RF components on the RF path. RF path of Dipole whip antenna ANT-DB1-RAF-RPS for WLAN...
- Page 3 Antenna Application Guidance RF path of Monopole PCB antenna for 5GHz WLAN and sub-G...
- Page 4 FCC Statements Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 5 FCC Statements (cont.) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 6 IC Statements This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 7 IC Statements (cont.) This equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. ce matériel est conforme aux limites de dose d'exposition aux rayonnements, FCC / CNR-102 énoncée dans un autre environnement.cette eqipment devrait être installéet exploité...
