WLAN+Bluetooth Module User Manual
Part Number: LBEE5HY2DU
LBEE5HY2DU has been FCC/ISED certified as Single Modular Approval with the following IDs.
FCC ID: VPYLB2DU
IC: 772C-LB2DU
The module is limited to OEM installation ONLY. The OEM integrator is responsible for ensuring that the end-user
has no manual instruction to remove or install module.
Therefore, the final host product must be submitted to Murata for confirmation that the installation for the
module into the host is in compliance with regulations of FCC and IC Canada. Specially, if an antenna other than
the model documented in the Filing is used, a Class 2 Permissive Change must be filed with the FCC.
Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate
the equipment.
This module has been approved by FCC to operate with the antenna types with the maximum permissible gain
indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device. The following antennas have been certified in combination
with the module. Refer to next pages for the antenna application guidance.
▪ PCB antenna with peak gains of +0.1dBi (2.4GHz) and -0.4dBi (5GHz);
