LBEE5XV2EA User Manual for FCC
Model Name:
LBEE5XV2EA
FCC ID:
VPYLBEE5XV2EA
Since this module is not sold to general end users directly, there is no user manual of module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification (installation procedure)
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove
this RF module in the end user's manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as shown in User manual.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This device complies with below part 15 of the FCC Rules.
Part 15 Subpart C
Part 15 Subpart E
Since there is no space which indicates FCC ID on this module, FCC ID is indicated in a manual. If the FCC ID is not visible when
the module is installed inside another device, then the module is installed must also display a label referring to the enclosed
module.
Model Name:
Variant Model
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
LBEE5XV2EB
06 July 2023
1
Advertisement
Related Manuals for Murata LBEE5XV2EB
Summary of Contents for Murata LBEE5XV2EB
- Page 1 Since there is no space which indicates FCC ID on this module, FCC ID is indicated in a manual. If the FCC ID is not visible when the module is installed inside another device, then the module is installed must also display a label referring to the enclosed module. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 2 10,000 feet. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
-
Page 3: Integration Instructions
Sections 2 through 10 describe the items that must be provided in the integration instructions for host product manufacturers (e.g., OEM instruction manual) to use when integrating a module in a host product. This Modular transmitter applicant(muRata) should include information in their instructions for all these items indicating clearly when they are not applicable. - Page 4 If the FCC ID is not visible when the module is installed inside another device, then the module is installed must also display a label referring to the enclosed module. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 5 Measure the spurious, and confirm degradation of less than 3dB than spurious value of worst of report used for the application. However it is spurious defined below. Please send those reports to Murata. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 6 It is necessary to take a SAR test with your set mounting this module (except to use only Bluetooth). Class II permissive change application is necessary using the SAR report. Please contact Murata. And an application for a Class II permissive change from a Mobile equipment to a Portable equipment is also required.
- Page 7 WT32D1-KX Unictron Dipole u.FL W24P-U Invertek Dipole u.FL Type2EA_Antenna Murata Monopole Trace ・W24P-U can only be used at 2.4GHz ・Type2EA_Antenna can only be used for ANT0(Antenna Port0) Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 8 Frequency Tolerance: ±20 ppm This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 9 Only the integrated antennas specified in the section 7 of this manual is allowed, when changes of antenna is requested, please contact Murata as further verification by Class II application is required. The finished product must be powered by a wired connection and not by battery power.
- Page 10 This module is only approval as a mobile equipment. Therefore, do not install it on portable equipment. If you wish to use it as a portable equipment, please contact Murata in advance as Class Ⅱ application accompanied by SAR testing using the final product are required.
- Page 11 9. Information on test modes and additional testing requirements: Applicable Please check the installation manual first. Please contact Murata if you have any questions when conducting the RF certification test on the host. We (Murata) are ready to present the control manual and others for the RF certification test.
- Page 12 —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 13 2)Technical document showing that the gain is the same or lower than the gain at the time of the original approval 3)Technical document showing that the spurious is no more than 3 dB worse than when it was originally certified Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
-
Page 14: About Power Supply
LBEE5XV2EA User Manual for FCC About Power supply Parameter Min. Typ. Max. unit VBAT Supply Voltage VDDIO 1.71 1.89 Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023... - Page 15 ２）An antenna gain is lower than a gain given in antenna specifications. ３）The emission level is not getting worse. The following is the design of the EVB used for the test. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 16 The 50ohm microstrip line and Type2EA_Antenna needs to be copied when module is installed in the End product. Murata provides set makers with Gerber data or something similar. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 17 : 6 Substrate thin : 0.8 ± 0.1 mm 2.5mm 6.6mm 2.0mm 1.2mm 2.8mm 2.3mm 7.5mm 7.5mm 0.3mm 0.7mm 1.3mm 3.0mm 1.9mm 7.8mm 1.8mm Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 06 July 2023...
- Page 18 Layout Guidance for Microstrip Design and External Antenna About Trace antenna(Type2EA_Antenna). The LBEE5XV2EA (LBEE5XV2EB) module is certified with a PCB antenna(Type2EA_Antenna). The following precautions should be taken when using this PCB antenna(Type2EA_Antenna). Type2EA_Antenna can only be used for port_ANT0 side.
- Page 19 U.FL RF connector as shown below. The microstrip RF trace and U.FL connector are placed on the customer‘s PCB and are external to the LBEE5XV2EA (LBEE5XV2EB) module. The antenna is then connected to this u.FL Connector via a 50ohm RF adapter cable.
- Page 20 The following guidance is predicated on the use of FR4 Dielectric. If FR4 is not used for PCB material, please contact Murata to determine new dimensions for microstrip structure. H (Dielectric Height) — this is the thickness of dielectric between the trace layer (layer 1) and the ground plane on layer 2.
- Page 21 However, regulatory and performance limitations practically determine the actual length to be used by the customer (integrator). The length of this microstrip line must be longer than 3 mm to mimic the length used during FCC/ISED certification of the LBEE5XV2EA (LBEE5XV2EB) module.
- Page 22 A condition for using this authorization is that the update package is systematized, managed by digital signatures, individual identification numbers, etc Inform our company that we have designed the FW and configuration files specified by Murata to be installed correctly when you are implemented in the final product Copyright ©...
