UWB+BLE Module User Manual
Part Number: LBUA5QJ2AB
LBUA5QJ2AB has been FCC/ISED certified as Single Modular Approval with the following IDs.
FCC ID: VPYLB2AB
The module is limited to OEM installation ONLY. The OEM integrator is responsible for ensuring that the end-user
has no manual instruction to remove or install module.
Therefore, the final host product must be submitted to Murata for confirmation that the installation for the
module into the host is in compliance with regulations of FCC and IC Canada. Specially, if an antenna other than
the model documented in the Filing is used, a Class 2 Permissive Change must be filed with the FCC.
Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate
the equipment.
This module has been approved by FCC to operate with the antenna types with the maximum permissible gain
indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device. The following antennas have been certified in combination
with the module. Refer to next pages for the antenna application guidance.
(a) TWR/TDoA antenna for UWB with peak gains of 3.9dBi (channel 5) and 2.8dBi (channel 9);
(b) AoA/PDoA antenna for UWB with peak gains of 1.8dBi (channel 5) and -1.5dBi (channel 9);
(c) PCB antenna for BLE with a peak gain of -4.7dBi;
IC: 772C-LB2AB
Advertisement
Related Manuals for Murata LBUA5QJ2AB
Summary of Contents for Murata LBUA5QJ2AB
- Page 1 Therefore, the final host product must be submitted to Murata for confirmation that the installation for the module into the host is in compliance with regulations of FCC and IC Canada. Specially, if an antenna other than the model documented in the Filing is used, a Class 2 Permissive Change must be filed with the FCC.
- Page 2 Antenna Application Guidance_ TWR/TDoA antenna Refer to js-0977-type 2cutag_antenna.dwg for antenna pattern. Contact Murata for the design file.
- Page 3 Antenna Application Guidance_ AoA/PDoA antenna Bottom Refer to js-0958_2ab certification board_pdoa_antenna.dxf for antenna pattern. Contact Murata for the design file.
- Page 4 Antenna Application Guidance_ PCB antenna for BLE Refer to js-0977-type 2cutag_antenna.dwg for antenna pattern. Contact Murata for the design file.
- Page 5 Unique antenna connector must be used on our Part 15 authorized transmitters used in the host product. Contact Murata for a list of acceptable unique connectors. Any deviation(s) from the defined parameters of the antenna trace, as described by this instruction, host product manufacturer must notify us that you wish to change the antenna trace design.
- Page 6 FCC&IC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 7 FCC&IC regulatory compliance statement (cont.) § 15.19 Labelling requirements shall be complied on end user device. § § Labelling rules for special device, please refer to 15.19 (a)(5) and relevant KDB publications. For E- 2.925, § label, please refer to 2.935.
- Page 8 FCC&IC regulatory compliance statement (cont.) This device is approved under Part 15.519 for handheld use. The use of antennas mounted on outdoor structures, e.g., antennas mounted on the outside of a building or on a telephone pole, or any fixed outdoors infrastructure is prohibited. Antennas may be mounted only on the hand held UWB device. UWB devices may not be employed for the operation of toys.
- Page 9 IC Statements This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 10 IC Statements (cont.) This equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. ce matériel est conforme aux limites de dose d'exposition aux rayonnements, FCC / CNR-102 énoncée dans un autre environnement.cette eqipment devrait être installéet exploité...
