Graf MINIMAX-PRO Instruction For Installation And Maintenance

Instruction for installation and maintenance
GRAF MINIMAX-PRO Filter internal
MINIMAX-PRO Filter internal
with straight outlet
Order No. 340119
For Platin and Carat tanks
The points described in these
instructions must be observed
under all circumstances. All
warranty rights are invalidated in
the event of non-observance.
Separate installation instructions
are enclosed in the transportation
packaging for all additional articles
purchased from GRAF.
The components must be checked
for any damage prior to installation
under all circumstances.
Missing instructions can be
downloaded on www.graf.info or
can be requested from GRAF.
info@graf.info
www.graf.info
Table of contents
1. General notes
1.1 Safety
2. Scope of supply
2.1 MINIMAX-PRO Filter internal components
2.2 MINIMAX-PRO Filter internal details
3. Technical data
3.1 Dimensions with straight outlet
4. Assembly
5. Installation and assembly
5.1 Overview Platin tank / Filter with straight outlet
5.2 Installation of inlet pipe, outlet pipe and overflow
siphon
5.3 Preparation filter for installation
5.4 Insert the filter into the tank
5. Installation and assembly
5.5 Overview Carat tank / Filter with straight outlet
5.6 Installation of inflow pipe and overflow siphon
5.7 Preparation filter for installation
5.8 Insert the filter into the tank
6. Commissioning & maintenance
1 / 9
2
2
2
2
2
3
4
4
4
6
6
7
7
7
8
8
9
9
