ENGO CONTROLS E7 Series Quick Manual

7
Product Compliance
This product complies with the following
Programmable, Wireless Thermostat
EU Directives: 2014/53/EU, 2011/65/EU
Safety information
Use in accordance with national and
EU regulations. Use the device only as
intended, keeping it in a dry condition.
E7-TXW / E7-TXB E7-RX
The product is for indoor use only.
Please read the entire manual, before
installation or use.
Quick Guide
Installation
Installation must be performed by
a qualified person with appropriate
Ver. 0.1
electrical qualifications, in accordance
Release date: VI 2025
Soft: v0.3
with the standards and regulations in
force in a given country and in the EU.
The manufacturer is not responsible for
non compliance with the instructions.
ATTENTION!
Producer:
Engo Controls sp. z o.o. sp. k.
For the entire installation, there may
Rolna 4 st.
43-262 Kobielice be additional protection requirements,
Poland
which the installer is responsible for.
www.engocontrols.com
Introduction
Engo E7 is a modern room thermostat that combines simplicity of operation with the
functionality needed for everyday thermal comfort. With a large, easy-to-read display
and simple 3-button control, operation is made as simple as possible. A default day/night
schedule makes it easy to get the system up and running quickly without programming. A
full weekly schedule option is also available for more demanding users. The E7 is available
in two colors - white and black - to match modern interiors. Thanks to radio communication
and factory pairing of the devices, installation is quick and hassle-free.
Product features
Operating modes: day/night HEATING/COOLING function
Simple and intuitive Wireless communication in the
device operation 868MHz standard
Maximum/minimum Devices are factory-paired with unique
rf
temperature limitation communication codes, which prevents
mutual interference
Technical data
Thermostat supply 2 x AA batteries
Receiver supply 230 V AC 50 Hz
Max load of the receiver 16 (5) A
Receiver outputs Voltage-free NO/COM relay
Temperature range 5 - 35°C
Display temperature accuracy 0,1 or 0,5°C
Control algorithm TPI or Histeresis (±0,2°C do ±2°C)
Communication Wireless, 868 Mhz
Dimensions [mm] thermostat: 80 x 80 x 22, receiver: 96 x 96 x 27
Wall mounting of the thermostat,
1 2
Screw the mounting Insert batteries in the
plate to the box/wall. thermostat.
Connection description
a) Connection diagram to the heating source
868MHz
Wireless
thermostat
L L N N COM NO
Battery power
supply
AC 230V
L
N
b) Connection diagram for the pump/actuator
868MHz
Wireless
thermostat
L L N N COM NO
Battery power
supply
AC 230V
L
N
PE
c) Connection diagram for the UFH control box
868MHz
Wireless
thermostat
L L N N COM NO
Battery power
supply
Legend:
Fuse
Pump
Battery power supply
Valve actuator
L, N 230V AC power supply
Wireless communication
PE Ground (electricity)
Voltage-free output
COM, NO
Boiler - Boiler connection * - Boiler's
contacts for ON/ OFF thermostat
Signal Live - input in the
SL..
(according to the boiler's instructions)
control box
LCD Icon Description
2 3
3
1
ROOM
TEMP
14
13
MO TU WE TH FR SA SU
12
Attach thermostat to the
mounting plate.
1
1. "Down" Button –
2. "OK" Button
3. "Up" Button +
Button Description
+ Change the parameter value up
Heating source
–
Change the parameter value down
*
Manual/Schedule mode - short button press
Enter the installer parameters/schedule/time setting - hold 3 seconds
Turn OFF/ON thermostat - hold 5 seconds
Pairing the transmitter with the receiver - hold until the SY message,
then release the keys
+ & –
Factory reset - hold until the FA message appears, then select YES and confirm
+
& Lock/Unlock thermostat keys - hold 3 seconds
– & Heating/Cooling mode change - hold 3 seconds
Receiver
max. 16(5)A
LEFT SWITCH
1. ON - Manual mode - receiver ON
2. OFF - Manual mode - receiver OFF
RIGHT SWITCH
3. MANUAL - Receiver works in Manual mode
(according to the left switch)
4. AUTO - Receiver works in AUTO mode
(according to the thermostat's command)
The green
LED is solid
N
L Control box
The green
1 - 8 Zone
SL..
LED flashes
The green
LED is off
The orange
LED is solid
The
orange
LED flashes
The
orange
LED is off
1. Current temperature
4 5
2. Status of the receiver connection
3. Heating indicator (icon is animating when
AM
there is heating demand)
6
PM
SET 4. Cooling indicator (icon is animating when
7
there is cooling demand)
8
5. Clock
9
PROG 6. Temperature unit
10
7. Setpoint temperature
11
8. Temporary override mode
9. Schedule mode icon
10. Program number
2 3
11. Day of the week indicator
12. Battery indicator
13. Button lock
14. Settings icon
1 2
1
The status of the receiver is
indicated by two LEDs. These are
LEDs with the following colors:
- green (upper one),
1
2 - orange
A DETAILED EXPLANATION OF THE MEANING OF THE LEDS:
The receiver is connected to the 230V power supply.
The receiver can be controlled by thermostat if it is in automatic mode when the right
switch is in the AUTO position.
The receiver can be controlled manually when the right switch is in the MANUAL position.
The receiver is in the pairing mode and is looking for a signal from the thermostat (then
you must activate the "SYNC" parameter in the thermostat).
The receiver is disconnected from the 230V powersupply
or the left switch is in the OFF position.
In automatic mode, the receiver received a heating / cooling signal from the thermostat.
The receiver was turned ON in manual mode (left ON switch, right MANUAL switch)
The receiver was paired but lost communication with the thermostat due to out of range
or low battery in the thermostat. The receiver starts flashing after 40 minutes of time
when it does not receive a signal from the thermostat.
The receiver does not send a heating / cooling signal.
3 4
2
(lower one).
