- Page 1 E901WIFI | Internet, wireless thermostat Ver. 1 Release date: IX 2022 Quick Guide Producer: Distributor: QL CONTROLS Sp z o.o. Sp. k. Engo Controls S.C. 43-262 Kobielice 43-200 Pszczyna 4 Rolna St. 3E Górnośląska St. Poland Poland www.engocontrols.com...
-
Page 2: Product Compliance
INTRODUCTION: E901WIFI is a wireless, Wi-Fi room thermostat which enables economical and ecological control of any type of heating. The operation of the thermostat is very simple and allows the user to adjust the heating cycle to user’ s rythm of the day. -
Page 3: Wall Mounting
Wall mounting Remove the thermostat cover as shown in the picture. If there are batteries inside, remove them Use a screwdriver to push the plastic tabs in as shown in the figure until you feel resistance, and tilt the front part of the housing. Separate the front part from the back part in the direction shown above Use the supplied mounting screws and mount the back cover to the wall (use holes as shown arrows) - Page 4 E901TXWIFI E901RXWIFI RECEIVER 2 x AA 1 - 8 Zones ECB08M230 Wiring centre E901RXWIFI receiver Receiver’s switches description: LEFT SWITCH ON - Manual mode - receiver ON OFF - Manual mode - receiver OFF RIGHT SWITCH MANUAL - Receiver works in manual mode (according to the left switch) AUTO - Receiver works in AUTO...
-
Page 5: Lcd Icon Description
LCD icon description 1. AM/PM 2. Clock 3. Day of the week indicator 4. Settings icon 5. Key lock function 6. Send a signal (pairing) 7. Internet connection 8. Holiday Mode 9. Low battery indicator 10. Antifrost Mode 11. Cooling mode 12. -
Page 6: Off Mode
Manual mode - temperature settings In manual mode, the thermostat maintains a constant setpoint temperature as long as the user will not change it again or will not switch to another operating mode (e.g. schedule mode). Setting setpoint temperature in manual mode Press any button to highlight the screen, then follow the steps below: Press... - Page 7 Installation of the E901WIFI thermostat in the app Make sure your router is within range of your smartphone. Make sure you are connected to the Internet. This will reduce the pairing time of the de- vice. Use only Wi-Fi 2,4GHz network...
- Page 8 STEP 3 - CONNECT THE THERMOSTAT TO WI-FI After installing the app and creating an account: 1. Turn on Wi-Fi and Bluetooth on your smartphone. Connect mobile phone to the Wi-Fi network to which you want to assign the thermostat. Connect the receiver to the power supply.
- Page 9 When the blue LED on the receiver will light up, it means the device has been correctly added to the application and is now connected to the Internet. E901WIFI pairing process with the receiver PLEASE NOTE! E901WIFI THERMOSTAT IS ALREADY PAIRED...
- Page 10 5 sek. Press and hold the button for 5 seconds. button to select SYNC parameter. Confirm with button. Using buttons choose YES and start the pairing process on a new frequency by pressing the button The thermostat started to send a signal to find the receiver (the symbol of the blinking antenna) and started the countdown with the number 10 (min).
-
Page 11: Installer Settings
Installer settings 5 sek. To enter installer parameters press and hold button for 5 seconds. . button to move between parameters. Enter the parameter by . Edit the parameter using . Confirm the new parameter value with the button. Installer parameters Default Function Value...
