Features

The Compaq Server Console Switch family of products is available in
2-, 4-, and 8-Port versions and can be used in various configurations to
accommodate large or small systems. All versions are packaged in space-
efficient 1U height (1.71-inch) cases.
This chapter provides an overview of the Server Console Switch features,
functionality, and sample configurations.
You can use the Server Console Switch in various configurations to connect
from 2 to 64 servers.
The features of the Server Console Switch include:
On-Screen Display (OSD) — Displays system-related information on
the monitor, such as power-up test data and configuration menus.
Programmable Scanning — Evaluates system performance by
sequentially scanning any or all of the computers in the system.
Programmable scanning allows you to determine which computers to
include as well as the duration of the connection.
Configuration NVRAM — Makes it easy to set configuration
information using commands entered from the keyboard. The NVRAM
(non-volatile RAM) stores the resulting configuration until you decide
to change the information, even if the unit loses power.
Hardware Reset Switch — Resets the unit without interrupting power
to the system if the keyboard or mouse communication is disrupted.
Password Protection — Protects against unauthorized users by
providing a password option for security purposes.
Switch Firmware Update — Allows quick and easy update since the
application code of the switch resides in FLASH. The port
communications settings are automatically configured to allow direct
downloading from the connected computer.
Alternate Language Selection — Provides alternate languages,
available on the Compaq Server Console Switch Software Utility CD.
(Not available for use with the 2-Port switch.) See this CD for additional
information.
Support for Optional Switch Box Connector Kit — Provides frontal
access to the 4- or 8-Port switches for a keyboard, monitor, mouse, and
power cord.
