Summary of Contents for Compaq Netelligent 1005
- Page 2 USE OF THIS MATERIAL. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. The software described in this guide is furnished under a license agreement or non-disclosure agreement.
- Page 3 ......Package Contents... 1 Hardware Description ... 2 LED Indicators ... 2 RJ-45 Ports ...
- Page 4 Please read through the following information to familiarize yourself with the hub’s features and installation requirements. Your package includes the following: Netelligent 1005 10Base-T Hub Hub stand Compaq Netelligent User Guide CD Compaq Netelligent 10Base-T Hub Quick Install Guide Power Adapter Warranty Registration Card...
- Page 5 ......This section describes the hub’s main components. The following illustration shows the hub’s front panel, back panel, and hub stand.
- Page 6 To connect to another Netelligent 1005 or compatible hub, attach straight- through twisted-pair cabling to the UPLINK port. You can also connect to another hub by running straight-through twisted-pair cabling from a station port on this hub to a crossover port on the other hub.
- Page 7 Follow these steps to connect the hub to devices in your network. Select an appropriate location. Connect a workstation to any available RJ-45 station port (1-5) on the hub using unshielded twisted-pair (UTP) cable. All connected devices must be within 100 meters of the hub. You can connect up to five workstations if you use the hub in a stand-alone configuration.
- Page 8 ......Symptom: The partition indicator lights steadily or flashes. Causes: The hub has a partitioned port, or a workstation’s network adapter or network software is defective.
- Page 9 The following table and illustrations show the pin wiring for both straight and crossover twisted-pair cable. (Note that crossover cable is required only if you cascade hubs using RJ-45 Ports 1-5; that is, the UPLINK port is not used.) Straight-Through (Hub) (Adapter) 1 IRD+...
- Page 10 ......Transmission Technique Topology Access Method Standard Conformance Media Supported Interfaces Hub-to-Workstation Distance Dimensions Power Requirements:...
- Page 11 This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
- Page 12 This product also complies with CISPR22 Class B (EN55022 Class B). This is to certify that the Compaq 1005 10Base-T Hub is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of...
- Page 13 ......This is to certify that this product complies with ISO/IEC Guide 22 and EN45014.
- Page 14 ......CE Mark Declaration of Conformance 7, 10 Class B 9 Crossover cable 6 CSA 7 Electrical outlet 4 Electrostatic discharge 9...
