EN User Manual
CZ Uživatelská příručka
SK Používateľská príručka
HU Felhasználói kézikönyv
PL Podręcznik użytkownika
PROFESSIONAL COLOUR WEATHER
STATION WITH 5-IN-1 SENSOR
PROFESIONÁLNÍ METEOROLOGICKÁ
STANICE S BAREVNÝM DISPLEJEM
A SNÍMAČEM 5V1
PROFESIONÁLNA METEOROLOGICKÁ
STANICA S FAREBNÝM DISPLEJOM
A SNÍMAČOM 5 V 1
PROFESSZIONÁLIS IDŐJÁRÁS-
ÁLLOMÁS SZÍNES KIJELZŐVEL
ÉS 5 AZ 1-BEN ÉRZÉKELŐVEL
PROFESJONALNA STACJA
POGODOWA Z KOLOROWYM
WYŚWIETLACZEM I CZUJNIKIEM 5 W 1
SWS 11000
Advertisement
Related Manuals for Sencor SWS 11000
Summary of Contents for Sencor SWS 11000
- Page 1 SWS 11000 EN User Manual PROFESSIONAL COLOUR WEATHER STATION WITH 5-IN-1 SENSOR CZ Uživatelská příručka PROFESIONÁLNÍ METEOROLOGICKÁ STANICE S BAREVNÝM DISPLEJEM A SNÍMAČEM 5V1 SK Používateľská príručka PROFESIONÁLNA METEOROLOGICKÁ STANICA S FAREBNÝM DISPLEJOM A SNÍMAČOM 5 V 1 HU Felhasználói kézikönyv PROFESSZIONÁLIS IDŐJÁRÁS- ÁLLOMÁS SZÍNES KIJELZŐVEL ÉS 5 AZ 1-BEN ÉRZÉKELŐVEL...
- Page 3 TABLE OF CONTENTS ............................... 2 ............................. 3 Quick start guide ............................4 PACKAGE CONTENTS ............................ 4 PRE INSTALLATION ............................4 Checkout..............................4 Site selection ............................. 5 ............................5 Wireless 5-in-1 sensor ..........................5 Install wireless 5-in-1 sensor array ......................5 Synchronizing additional sensor(s) (optional) ....................
- Page 4 ABOUT THIS USER’S MANUAL This symbol represents a warning. To ensure safe use, always adhere to the instructions described in this documentation. This symbol is followed by a user’s tip. – Keeping and reading the “User manual” is highly recommended. The manufacturer and supplier cannot accept any responsibility for any incorrect readings, export data lost and any consequences that occur should an inaccurate reading take place.
- Page 5 during use, storage or transportation. – Replacement of a battery with an incorrect type can result in an explosion or the leakage of flammable liquid or gas. result in an explosion. explosion or the leakage of flammable liquid or gas. –...
- Page 6 Quick start guide station, along with references to the pertinent sections. Step Power up the 5-in-1 wireless sensor array Power up the display console and pair with sensor array Manually set time, date and unit of measure PACKAGE CONTENTS Weather station Extend wall mount Power adaptor User manual...
- Page 7 Site selection Before installing the sensor array, please consider the followings; should be installed at 1.5m (5’) from any building, structure, ground or roof top. 4. Choose an area of open space in direct sunlight without any obstruction of rain, wind, and sunlight. 5.
- Page 8 Battery and installation Unscrew the battery door at bottom of unit and insert the batteries according to the +/- polarity indicated. Screw the battery door compartment on tightly. NOTE: – Ensure the water tight O-ring is properly aligned in place to ensure water resistant.
- Page 9 Step 4 Place the nut in the hexagon hole of the stand, then insert the screw in other side and then Install the wireless 5-in-1 sensor Add rubber pads in an open location with no before mount on the pole sensor for accurate rain and wind Point to measurement.
- Page 10 Synchronizing additional sensor(s) (optional) The console can support 7 wireless thermo-hygro sensors and pool sensors. Please contact your local retailer for details of different sensors. Some of these sensors are multi-channel. Before inserting the batteries, set the channel number if please refer to the manuals that come with the products.
- Page 11 Setup the console Power up the display console 1. Install 3 pcs AAA back-up batteries Step 1 Step 2 Step 3 Insert 3 pcs new AAA batteries Replace the battery door door 2. Connect the display console power jack to AC power with the adaptor included. NOTE: –...
- Page 12 NOTE: If no display appears when power up the console, you can press [RESET] key by using a pointed object. If this process still not work, you can remove the backup battery and unplug the adapter then re-power up the console again. Synchronizing wireless 5-in-1 sensor array Immediately after power up the console, while still in synchronization mode, the 5-in-1 sensor array can be paired to the console automatically (as indicated by the flashing antenna...
- Page 13 Key / Part Name ALARM/SNOOZE Press to stop alarm sound Press to toggle between gust, 10 minutes gust and past 12 hours gust scale RAIN Press to toggle between rain rate and rainfall of different period Graph Press to toggle between barometric pressure and rainfall graph Battery compartment Power jack Hold 2 seconds to enter time, date and other settings...
- Page 14 Radio controlled / atomic clock function daily. Signal strength indicator No signal quality Weak signal quality Acceptable signal Excellent signal quality quality NOTE: – Everyday the unit will automatically search for the time signal at 2:00am, 8:00am, 2:00pm and 8:00pm. –...
- Page 15 Step Mode Setting procedure [SET] Press [ ] or [ RCC signal. – ON is add one hour on current default time. [SET] Hemisphere Press [ ] or [ ] key to select North / South hemisphere for moon phase and wireless sensor array point to direction. [SET] Weekday Press [...
- Page 16 To turn on / off alarm clock (with ice-alert function) 1. In normal mode, press [ALARM] key anytime to show the alarm time. 2. Press [ALARM] 3. Press [ALARM] 4. To disable the alarm, press until the alarm icon disappears. Alarm off Alarm on Alarm with ice-alert...
- Page 17 Step Mode Setting procedure [ALERT] Press [ ] or [ Press [ALARM] key to on / off the alert. [ALERT] Press [ ] or [ Press [ALARM] key to on / off the alert. [ALERT] OUT humidity high alert Press [ ] or [ Press [ALARM] key to on / off the alert.
- Page 18 Outdoor temperature and humidity 1. Outdoor signal strength indicator 2. Outdoor sensor low battery indicator 4. HI / LO Alert indicator 5. Trend indicator Wind chill reading 7. Outdoor humidity reading NOTE: If temperature / humidity is below or above the measurement range, the reading will show “LO” or “HI”...
- Page 19 sensor. Indoor and optional CH 1~ 7 temperature and humidity Indoor screen 1. Trend indicator 2. HI / LO Alert indicator 3. Comfort indicator 4. Indoor temperature reading 5. Indoor humidity reading Thermo-hygro sensor screen (optional sensor function) 1. Indoor / CH 1~7 auto loop icon 2.
- Page 20 Sunny Slightly Cloudy Cloudy Rainy Rainy/Stormy Snowy NOTE: – The accuracy of a general pressure-based weather forecast is about 70% to 75%. – The weather forecast is meant for the next 12 hours, it may not necessarily reflect the current situation.
- Page 21 Rain 2. Rain rate high alert indicator 3. Period of rainfall and rain rate indicator 4. Rainfall or rain rate reading Rainfall display mode In normal mode, press [RAIN] key to toggle between: – RATE - current rainfall rate (base on 10 min rain data) –...
- Page 22 Wind speed 1. Gust, 10 minutes gust or past 12 hours gust reading 5. Wind speed or Beaufort scale reading Wind speed display mode In normal mode: Press key to toggle between: Gust 10 minutes gust past 12 hours gust. Press and hold reading.
- Page 23 Beaufort scale Beaufort Scale Wind Speed Land Condition < 1 km/h < 1 mph Calm < 1 knot < 0.3 m/s 1.1 ~ 5.5 km/h 1 ~ 3 mph Light air 1 ~ 3 knot 0.3 ~ 1.5 m/s 5.6 ~ 11 km/h 4 ~ 7 mph Light breeze 4 ~ 6 knot...
- Page 24 Beaufort Scale Wind Speed Land Condition 103 ~ 117 km/h 64 ~ 73 mph Violent storm 56 ~ 63 knot 28.5 ~ 32.6 m/s Hurricane force about. Trend indicator The trend indicator shows the temperature humidity and barometric pressure trends of changes in the forthcoming few minutes.
- Page 25 Past 24 hours history data The console automatically stores the weather data of the past 24 hours. In normal mode, press key to check the beginning of the current hour’s weather data, e.g. the current time is 7:25 am, March 8, the display will show the data of 7:00am, March 8. Press (Mar 8), 5:00am (Mar 8), …, 10:00am (Mar 7), 9:00am (Mar 7), 8:00am (Mar 7) In History mode:...
- Page 26 Reset and factory reset To reset the console and start again, Press [RESET] unplug the adapter. CLEANING THE RAIN COLLECTOR 1. Rotate the rain collector by replacement turning it 30° anti-clockwise. collector. debris or insects. 4. Install the collector when it is clean and fully dried.
- Page 27 TROUBLESHOOTING Problem / Symptom Solution Rainfall is not correct 1. Make sure the rain collector is clean for the tipping bucket to tip smoothly ensure correct tipping Temperature reading too high in 1. Place the sensor in open area and at least 1.5m off the the day time ground.
- Page 28 Accuracy Resolution Humidity unit Accuracy Resolution Temperature unit Accuracy Resolution Humidity unit Accuracy Resolution Wind speed unit mph, m/s, km/h, knots Wind speed display range 0~112mph, 50m/s, 180km/h, 97knots Wind speed resolution 1 decimal place (mph, m/s, km/h and knots) Accuracy 16 directions or 360 degree Rainfall unit...
- Page 29 Adapter technical specifications: Manufacturer’s name or trade mark, commercial registration number and address: No.200, Technology East Road, Shijie Town, Model identifier: AC100 - 240V Input AC frequency: 50/60Hz 4.75-5.25V Output current: 0.6A Output power: 3.0W 69.64% Efficiency at low load (10 %): 58.84% No-load power consumption: EN - 27...
- Page 30 The improper disposal For business entities in the European Union information from your seller or supplier. If you wish to dispose of this product, request the necessary information about the correct The product meets EU requirements. www.sencor.com info@sencor.cz EN - 28...
- Page 31 FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic info@sencor.com Authorized service centers: Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
- Page 32 FAST ČR, a.s.
