HITROL HT-100CT-2 Series Instruction Manual
Capacitance type level transmitter
Hide thumbs
Also See for HT-100CT-2 Series:
- Instruction manual (20 pages) ,
- Instruction manual (28 pages)
Advertisement
Quick Links
HT(HPC)-100CT-2 Series
HITROL CO., LTD.
HEAD OFFICE.FACTORY.R&D INSTITUDE
HITROL CO., LTD. 141, Palhakgol-gil, Jori-eup
Paju-si, Gyeonggi-do, Korea
TEL. : (00)-82-31-950-9700
FAX. : (00)-82-31-943-5600
www.hitrol.com
INSTRUCTION MANUAL
CAPACITANCE TYPE LEVEL TRANSMITTER
HT-100CT-2 Series
HPC-100CT-2 Series
Doc. no : HT(HPC)100CT2_IM_Eng_Rev.6.4
Issue date: 2023. 09
HITROL CO., LTD.
1
Advertisement
Related Manuals for HITROL HT-100CT-2 Series
Summary of Contents for HITROL HT-100CT-2 Series
- Page 1 HT(HPC)-100CT-2 Series HITROL CO., LTD. HEAD OFFICE.FACTORY.R&D INSTITUDE HITROL CO., LTD. 141, Palhakgol-gil, Jori-eup Paju-si, Gyeonggi-do, Korea TEL. : (00)-82-31-950-9700 FAX. : (00)-82-31-943-5600 www.hitrol.com INSTRUCTION MANUAL CAPACITANCE TYPE LEVEL TRANSMITTER HT-100CT-2 Series HPC-100CT-2 Series Doc. no : HT(HPC)100CT2_IM_Eng_Rev.6.4 Issue date: 2023. 09...
- Page 2 You should be aware of where NOTICE is Marking · · · · · · · · · · · · · · · · · · · · · · · · 12 marked to carry out the work. HITROL CO., LTD.
- Page 3 ΔC. ε₁ : Dielectric constant of air ε₂ : Dielectric constant of medium (contents) : Height of tank : Level of medium (contents) : Outer diameter of tank : Outer diameter of sensing probe HITROL CO., LTD.
- Page 4 (Ex d IIC T4, IP65) Wetted Parts Material SUS 304, 316L with Teflon Process Connection PT 1”(M) Screw 50A JIS 10K RF Flange Housing ; Cable Entry AL. ; PF 3/4”(F) Accuracy Up to ±0.5% of F.S HITROL CO., LTD.
- Page 5 Teflon material: SS, Teflon material: SS w/ material: Teflon SS w/ Teflon Wire Probe Rod Probe Wire Probe Wire Probe Rod Probe Rod Probe with Ground Wire with Ground Tube with Ground Wire (Corrosion) with Ground Rod HITROL CO., LTD.
- Page 6 Hexane, Liquid Butanol 17~18 Ammonia 16~25 Alcohol 16~31 Acetone Caustic soda 22~26 Ethanol Methanol 32~33 Glycerin 47~68 Water Sulfuric acid The data of dielectric constant value can be downloaded from technical data by accessing our website www.hitrol.com. HITROL CO., LTD.
- Page 7 (e) When installing the product, verify the size of the product insert and the size of the nozzle in the tank before installing the product to the applicable standards. (ex. Ground tube, Ground Sensor, Weight, etc.) Max. HITROL CO., LTD.
- Page 8 ■ Ground tube type shall be applied for ball tank and external chamber shall be installed for side mounting of tank. (h) ■ When side mounting, the chamber shall be installed. (i) ■ The ground tube shall have vent holes in an appropriate location. ( j) ( j) Vent holes HITROL CO., LTD.
- Page 9 When installing on a conductive tank, the transmitter housing and tank shall be grounded as shown below. ■ Non-metal tanks (Non-conductive tank) When installed on a non-conductive tank, use the ground tube (rod) or ground wire type. Also, the transmitter housing and tank shall be grounded as shown below. HITROL CO., LTD.
- Page 10 ▶ Noise on the lines ▶ Extreme fluctuation of medium ▶ Bad insulation of probe Output indicates full (20mA) of higher regardless of the change of level of the medium. ▶ Wrong adjustment of ZERO and SPAN HITROL CO., LTD.
- Page 11 - Do not apply high impact to the product. Precautions for Wiring ■ - Make sure to wire contacts correctly. (Refer to Wiring) - Wire and supply the power to the device after checking the specifications. - Pay attention to prevent electric shock. HITROL CO., LTD.
- Page 12 You can request A/S at our website or by contacting our headquarters. ■ Headquarters ․ Factory ․ Laboratory Contact Number ADDRESS: HITROL CO., LTD 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea T E L : 031-950-9700 (Headquarters & A/S) F A X : 031-943-5600 (Headquarters & A/S)
- Page 13 APPENDIX V M-100CT2 User Manual Capacitance Type Level Transmitter Doc. no. : Rev.2.0 Issued Date : 2025.04.01 Version : 25C55 ~...
- Page 14 1. Configuration of Module (M-100CT2) Composition Function ■ Function setting S Key ■ Save the setting ■ Mode Change M Key ■ Cancellation ■ Span Set ▲ Key ■ Setting the value left / up ■ Zero Set ▼ Key ■...
- Page 15 2. Specification Items Specifications Enclosure Weather Proof Material Microprocessor 16Bit Microprocessor Current Loop Interface 2-Wire Loop Current Supply Voltage DC +17V ~ +40V @ Typ. +24V 4.0mA ~ 20mA @ ±0.5% F.S Output Current Accuracy ■ 3.8mA ~ 20.5mA @ Alarm 3.6mA, 21mA[NAMUR NE43] Output Current Range ■...
- Page 16 3. Configuration of Setting Menu Contents Description Note 16 : mA Bit : Percent ( ※ [02]. [03] Setting Unit ) [00] mA / % Unit Set : Level : Distance [01] Level / Distance Set Quick Menu [02] Zero Point Set 0.0 ~ 95.0% or 4.000 ~ 19.200mA Setting Quick Menu [03]...
- Page 17 4. Setting and Operating Setting and Operating DISPLAY MODE DISPLAY MODE ■ LCD Configuration mA Mode mA Mode Percent Mode Percent Mode Meter Mode Meter Mode Feet Mode Feet Mode Level Mode Level Mode(User Setting) Distance Mode Distance Mode(User Setting) Rotation Mode Rotation Mode Setting Mode...
- Page 18 ■ Select the Setting Menu Setting Menu ■ Change the User Setting Change the User Setting Shift Digit Change Value Key Button Key Button Function Press more than 1 sec. Press more than 1 sec. Increasing of digits(Left) Press more than 1 sec. Press more than 1 sec.
- Page 19 ■ Height Setting ▶ Zero Height From bottom of tank to zero position ▶ Span Height: From bottom of tank to span position. ▶ Tank Height From bottom of tank to highest level of medium in the tank. ▶ Distance From top of tank to medium ■...
- Page 20 ■ Zero, Span Quick Setting □ Setting Screen Percent Setting mA Setting ※ The default unit is set to “%”. □ Zero Setting Contents Quick Menu Setting Zero Setting Press for 1 sec. input the value Press for 1sec. □ Span Setting Contents Quick Menu Setting Span Setting...
