HITROL HT-100PT Instruction Manual

Pressure type level transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HITROL CO., LTD.
HEAD OFFICE.FACTORY.R&D INSTITUDE
HITROL CO., LTD. 141, Palhakgol-gil, Jori-eup
Paju-si, Gyeonggi-do, Korea
TEL. : (00)-82-31-950-9700
FAX. : (00)-82-31-943-5600
www.hitrol.com
INSTRUCTION MANUAL
PRESSURE TYPE LEVEL TRANSMITTER
HITROL CO., LTD.
HT-100P Series
HT-100PT
HT-100PS
Doc. no.: HT100P_IM_Eng_Rev.1
Issue date: 2020. 09
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-100PT and is the answer not in the manual?

Questions and answers

Related Manuals for HITROL HT-100PT

Summary of Contents for HITROL HT-100PT

  • Page 1 HT-100P Series HITROL CO., LTD. HEAD OFFICE.FACTORY.R&D INSTITUDE HITROL CO., LTD. 141, Palhakgol-gil, Jori-eup Paju-si, Gyeonggi-do, Korea TEL. : (00)-82-31-950-9700 FAX. : (00)-82-31-943-5600 www.hitrol.com INSTRUCTION MANUAL PRESSURE TYPE LEVEL TRANSMITTER HT-100PT HT-100PS Doc. no.: HT100P_IM_Eng_Rev.1 Issue date: 2020. 09 HITROL CO., LTD.

  • Page 2: Table Of Contents

    Warranty & Contact · · · · · · · · · · · · · · · · · · · · · 7 out the work. Y ou should be aware of where NOTICE is marked to carry out the work. HITROL CO., LTD.

  • Page 3: Over View

    50A JIS 10K RF Flange (Std.) 50A JIS 10K RF Flange (Std.) Process Connection PF 1”(M) Screw PT 1”(M) Screw AL. : PF 1/2”(F), IP66 Housing ; Cable Entry PBT : PF 1/2”(F), IP65 Accuracy ± 0.25 % F.S HITROL CO., LTD.

  • Page 4: Products & Dimension

    ■ (The gaskets should be selected considering the temperature of the content and the pressure of the container.) The user should install appropriate products after judging whether the products are to be ■ used in explosion-proof regions. HITROL CO., LTD.

  • Page 5: Wiring

    ▶ Check that the measuring object is fluctuating a lot. Output indicates full (20mA) of higher regardless of the change of level of the medium. ▶ Check the AMP or Pressure Sensor for abnormalities. ▶ Check that zero, span adjustment is correct. HITROL CO., LTD.

  • Page 6: Precautions For Removal

    - Make sure to separate the amplifier and main unit from housing before disposing the products. Also, the amplifier shall be detached and discard the metal and non-metallic materials. No part (ex. Mercury switch) has influence on the environment, so no special attention is required. HITROL CO., LTD.

  • Page 7: Marking

    You can request for A/S through our website or by contacting our headquarters. ■ Headquarters 〮 Factory 〮 Laboratory Contact Number Address : HITROL CO.,LTD 141, Palhakgol-road, Jori-eup, Paju-si, Gyeonggi-do, Korea TEL : 031-950-9700 (Headquarters and A/S) FAX : 031-943-5600 (Headquarters and A/S)
  • Page 8 APPENDIX K HT-100P DISPLAY Setting Guide Pressure Type Level Transmitter Doc. no. : Rev2.0 Issued Date : 2020.09.25...
  • Page 9 1. HT-100P DISPLAY Module Composition & Function Composition Function ■ Function Setting S Key ■ Save the setting ■ Mode change M Key ■ Cancellation ■ Span set ▲ Key ■ Setting the value left / up ■ Zero set ▼...
  • Page 10 2. Amplifier Specification Item Specification Enclosure Weather Proof Material P.B.T / AL.C Mounting 100PT (Top Mounting) / 100PS (side Mounting) Microprocessor 16Bit Microprocessor Current Loop Interface 2-Wire Loop Current Supply Voltage DC+17V ~ DC+35V @ Typ.+24V Output Current Accuracy 4.0mA ~ 20.0mA @ ±0.25% F.S Measuring Range 0 ~ 200KPa (2bar / 20.4mH2O) @ Gauge Pressure 4.0mA ~ 20.0mA @ NAMUR NE43 Holding...
  • Page 11 3. Setting Menu Function Contents Description Remarks [00] mA / % Unit Set : mA, : percent (※ [02], [03] setting unit) [01] Level / Distance Set : Level, : Distance Quick Menu [02] Zero Point Set 0.0 ~ 95.0% or 4.000 ~ 19.200 mA setting Quick Menu 5.0 ~ 100.0% or 4.800 ~ 20.000 mA setting [03]...
  • Page 12 4. Operating Method ■ LCD Composition Display Mode Cursor (User setting) (User setting) Segment Bar graph The cursor moves sequentially whenever the button is pressed. The order of movement is as follows. ■ Into the Setting Menu About 1sec. In the Setting Mode, press button for 1 second then the green LED will be flickering and you can go into the Setting Menu.
  • Page 13 ■ Select Setting Menu About 1sec. In the Setting Menu, use buttons to select the user setting function. Pressing button for 1 second will enter the function. ■ Change the User Setting Change of digits And value If just 1 digit is flickering, it can be moved between the digits. If full digits are flickering, it can only be set up to the specified number.
  • Page 14 ■ Height Setting ■ Level This refers to the direction in which the medium is raised based on the bottom of the tank. ■ Zero Height The distance from the bottom of the tank to the zero point is called “Zero Height”.
  • Page 15 5. UART Monitoring ■ Monitoring method □ You can only check the state of the adjusted setting values using your PC or Smartphone □ The method of using PC and Smartphone is the same. (Password : 1975) □ You can check the sensor measurement status, sensitivity setting value, relay setting status, etc.
  • Page 16 Unit Set Height Set (Based on level) Height Set (Based on level) Height Set (Based on level) Auto Zero / Span Set (Based on level) Function Set Apply Pressure Sensor Setting Input Calibration value by Sensor Type Adjustment Adjustment Select Reset Capacity Value of Current Measured Capacity Value of Span Setting...
  • Page 17 ■ Monitoring using a Smartphone □ Component : Smartphone(Android OS), OTG, USB Extension cable (typical USB to Micro USB B), UART ADAPTOR. □ Application : Refer to “Serial USB Terminal Install & Setting Guide” [USB ADAPTOR] [USB Extension cable] [HT-100P PC Smartphone UART Composition] [Enter PW and Fly command] [Continue] [Open App]...
  • Page 18 APPENDIX H Serial USB Terminal Serial USB Terminal Install & Setting Guide Application : Level Switch / Level Transmitter Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 19 ■ Installing Serial USB Terminal App □ Search and Install a App that "Serial USB terminal" in the App Store. ■ Serial USB Terminal Setting □ Run The Serial USB Terminal Icon □ Four types of environments must be set up for normal operation of Serial USB Terminal. ▶...
  • Page 20 ■ Serial – Baud rate Setting □ Baud rate : 19200 -> 9600 [Complete] [Select Baud rate] [Setting] [Default] ■ Terminal - Show connection message / Show timestamps Setting □ Show connection message : ON -> OFF □ Show timestamps : ON -> OFF □...
  • Page 21 ■ Receive – Newline Setting □ Newline : CR+LF (Carriage Return + Line Feed) Check [Default] ■ Send - Newline Setting □ Newline : Auto(same as Receive) -> CR [Select Newline] [Default] [Setting] [Complete] Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 22 ■ Send - Character delay Setting □ Character delay : 0ms -> 5ms [Complete] [Setting] [Default] [Select Character delay] ■ Send – Local echo / Clear input on send Setting □ Local echo : ON -> OFF □ Clear input on send : OFF -> ON [Complete] [Complete] [Select Local echo]...
