HT-100M Series
HITROL CO., LTD.
HEAD OFFICE.FACTORY.R&D INSTITUDE
HITROL CO.,LTD. 141, Palhakgol-gil, Jori-eup
Paju-si, Gyeonggi-do, Korea
TEL. : (00)-82-31-950-9700
FAX. : (00)-82-31-943-5600
www.hitrol.com
INSTRUCTION MANUAL
MAGNETOSTRICTIVE TYPE LEVEL TRANSMITTER
HT-100M Series
Doc. no.: HT100M_IM_Eng_Rev.0.0
Issue date: 2024. 10
HITROL CO., LTD.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HITROL HT-100M Series
Summary of Contents for HITROL HT-100M Series
- Page 1 HT-100M Series HITROL CO., LTD. HEAD OFFICE.FACTORY.R&D INSTITUDE HITROL CO.,LTD. 141, Palhakgol-gil, Jori-eup Paju-si, Gyeonggi-do, Korea TEL. : (00)-82-31-950-9700 FAX. : (00)-82-31-943-5600 www.hitrol.com INSTRUCTION MANUAL MAGNETOSTRICTIVE TYPE LEVEL TRANSMITTER HT-100M Series Doc. no.: HT100M_IM_Eng_Rev.0.0 Issue date: 2024. 10 HITROL CO., LTD.
-
Page 2: Table Of Contents
HT-100M Series Table of Contents Overview · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 Installation · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10 Characteristics·... -
Page 3: Overview
HT-100M Series Overview HT-100M Series are MAGNETOSTRICTIVE TYPE LEVEL TRANSMITTER that continuously measure water levels in containers using buoyancy. These transmitters can be easily installed and adjusted and can be used for chemicals because PVC and Teflon are used on their detecting elements. -
Page 4: Specifications
HT-100M Series Specifications STAINLESS STEEL HT-100MS Model Std. Opt. Mounting Banding at HLG-100F Flange Process Temperature Max. 90℃ Process Pressure None Up to 20kg/cm2(300#) Power Source DC +24V Output DC 4~20mA(2-wire) Accuracy ±1mm or ±0.1% @ F.S whichever is greater Enclosure Weather-Proof IP65 / IP66. -
Page 5: Float Application
HT-100M Series Float Environment Application Float Temp. (℃) Press. (㎏/㎠) Acid Alkaline Solvent Liquid gas SUS 316L -40 ~ +150 Up to 20 △ ○ ○ ◎ △ -10 ~ +60 ○ ○ △ TEFLON -20 ~ +150 0.5~3 ◎... - Page 6 HT-100M Series Float Application Table Dimensions (mm) Guide Product Size Material S.G Range Tube Ø28 Ø9.5 Ø8 316L 0.9~1.4 1" Ø26 Ø9.5 Ø8 발포 NBR 0.8~1.3 Ф49 Ф15.5 Ф12.7 316L 0.7~1.0 Ф50 Ф20 Ф15.8 0.6~0.9 2" Ф42 Ф15 Ф12.7 316L 0.8~1.3...
-
Page 7: Product Composition
HT-100M Series Product Composition Aluminum Housing (IP66) Housing (IP65) MAX. 90℃ MAX. 90℃ Flange Flange Flange Flange 304, 316L 304, 316L 304, 316L, W/TEFLON Stopper Stopper Stopper Stopper 316L 316L TEFLON Guide Tube Guide Tube Guide Tube Protection Tube Guide Tube... -
Page 8: D I M E N S I O N S
HT-100M Series Dimensions HT-100MS HT-100MV HT-100MT Flap Type Level Gauge with HT-100MS HT-100MS HT-100MS + HLG-100F VENT PLUG : L1= A+30mm VENT VALVE /w PLUG : L1= A+100mm HITROL CO., LTD. -
Page 9: Maintenance
HT-100M Series Maintenance The main inspection part of the HT-100M Series level transmitter is divided into the sensor part and the transmission part. The sensor part consists of coil board, magnetostrictive wire, and float, and the transmission part has M-100MD. The life of the main part depends on the user's environment and can be used in optimal condition through periodic inspection. -
Page 10: Installation
HT-100M Series Installation Below recommendation shall be considered when installation. The product may malfunction if the product has When there is flow or sloshing in the been installed at the inlet through which the measured object or there is agitator measure object flows in. -
Page 11: Safety And Environment
HT-100M Series Safety and ■ Precautions for Use Environment - Make sure to connect the product and vessel using required tools for sure. - Keep the lock key safe and make sure that it is locked. - Do not apply high impact to the product. -
Page 12: Failure Modes And Actions
PTFE Float and Tube have a warranty period of one year after the product is shipped. ■ Headquarters ․ Factory ․ Laboratory Contact Number ADRESS: HITROL CO., LTD 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea T E L : 031-950-9700 (Headquarters & A/S) F A X : 031-943-5600 (Headquarters & A/S) - Page 13 APPENDIX Z M-100MD User Manual Magnetostirctive Type Level Transmitter Doc. no.: Rev0.0 Issue date: 2024.10.08...
- Page 14 1. M-100MD Module Configuration & Function Configuration Function ■ Function setting S Key ■ Save the setting ■ Mode change M Key ■ Cancellation ■ Span Set ▲ Key ■ Setting the value left & up ■ Zero Set ▼ Key ■...
-
Page 15: Specifications
2. Specifications Items Specifications Microprocessor 16Bit Microprocessor Current Loop Interface 2-Wire Loop Current Supply Voltage DC+17V ~ +40V @ Typ.+24V Output Current Accuracy 4.0mA ~ 20.0mA @ ±0.1% F.S Output Current Range ■ 4.0mA ~ 20.0mA @ Alarm 3.8mA, 21mA [NAMUR NE43] Field Ground ■... - Page 16 3. Configuration of Setting Menu Content Description Remarks [00] Select Unit : mA / % : mA : % (※ Unit Setting for [02], [03]) Quick [01] Select Level / Distance : Level : Distance Menu Setting 0.0% ~ 95.0% or 4.000 mA ~ 19.200 mA Quick [02] Zero Setting...
-
Page 17: Display Mode
4. Setting and Operating Setting and Operating Display Mode Display Mode Whenever Whenever button is pressed, Display Mode is switched button is pressed, Display Mode is switched sequentially. sequentially. ※ Rotation mode ( ) show each display mode automatically at interval of 1 second by default. ) show each display mode automatically at interval of 1 second by default. - Page 18 □ How to select the Setting Menu Press Each Setting Menu can be switched by usage of arrow ( ) buttons. Press S button for 1 second to set of each function referring of below table. □ How to change the setting value Shift Digit Change Value “Flickering only one Digit”: It is available to shift to the other digit.
-
Page 19: Zero Setting
■ Definition of Height ▶ Zero Height From bottom of tank to center of float at zero position ▶ Span Height: From bottom of tank to center of float at span position. ▶ Tank Height From bottom of tank to highest level of medium in the tank. ▶...
