INSTRUCTION MANUAL
INSTRUCTION
FLOAT TYPE LEVEL TRANSMITTER
TYPE LEVEL TRANSMITTER
Doc. No.: HT100F_
HITROL CO., LTD.
HITROL CO., LTD.
HT-100F Series
HT-100F Series
HT
HT-100FI Series
HT
o.: HT100F_IM_Eng_Rev.3.1
Date Issued: 2023.09
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HITROL HT-100F Series
Summary of Contents for HITROL HT-100F Series
- Page 1 HT-100F Series HITROL CO., LTD. HEAD OFFICE. FACTORY. R&D INSTITUTE R&D INSTITUTE HITROL CO., LTD., 141, Palhakgol 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea TEL.: (00)-82-31-950-9700 FAX: (00)-82-31-943-5600 www.hitrol.com INSTRUCTION INSTRUCTION MANUAL FLOAT TYPE LEVEL TRANSMITTER TYPE LEVEL TRANSMITTER HT-100F Series HT-100FI Series Doc.
-
Page 2: Table Of Contents
HT-100F Series Table of Contents Overview and Features · · · · · · · · · · · · · · · · · · · 3 Cautions for Installation · · · · · · · · · · · · · · · · 10 Cautions for the Inserted External Wire ·... -
Page 3: Overview And Features
HT-100F Series Overview and The HT-100F Series is a float-type level transmitter for continuously measuring and Features the liquid level in a container with buoyancy. It is mainly used to measure liquid for purification, industrial water, sewage treatment plants, wastewater, and fuel tanks. -
Page 4: Specifications
HT-100F Series Specifications Model HT-100F HT-100FI Mounting Top, Flange Indicator None 1-point dial −20°C ~ +60°C Ambient Temperature Process Temperature Max. 80°C Process Pressure Range (m) Max. 7.5m Power Source DC 24V None (Std.) / DC 24V (Opt.) Output Display (Std.) / DC 4~20mA (2-wire) DC 4~20mA (2-wire) (Opt.) -
Page 5: Float Application Table
HT-100F Series Float Application Table Float Size Range Spring Length Outer MEAS. Range Length Diameter 5 m / ~3.5 m 89.1 7.5 m / ~6 m 10 m / ~7.5 m 5 m / ~3.5 m 76.3 7.5 m / ~6 m 10 m / ~7.5 m... -
Page 6: Dimensions
HT-100F Series Dimensions <HT-100F> <HT-100FI> <HT-100FI Guide Type> Wiring M-100R (R/I CONVERTER) ■ + -: DC 24V(DC 4~20mA Loop) ■ FG: Frame Ground ■ H, C, L: Terminals between Sensor and M-100R * Cable Color: H – Red, C – White, L – Black Make sure to connect the power with correct polarity (+, −). -
Page 7: Zero/Span Adjustment
HT-100F Series Zero/Span Adjustment Step 1 Step 2 Step 3 Step 4 Green LED is turned on Press and hold the button for 1s Press the button Press the button when the power is connected to finish zero/span setting with... -
Page 8: Maintenance
HT-100F Series Maintenance The HT-100F Series level transmitter requires 100F Series level transmitter requires inspection for the sensor, drive, and inspection for the sensor, drive, and transmission sections. The sensor section has REED S/W; the drive section has The sensor section has REED S/W; the drive section has The sensor section has REED S/W;... -
Page 9: Attachment And Cautions
HT-100F Series Attachment and Cautions If it is installed on the inlet, install a guide, When there is flow or sloshing in the measured or make it distanced from the inlet to object or there is agitator around the sensor, the prevent malfunction. -
Page 10: Cautions For Removal
HT-100F Series ■ Check the level and presence of liquid in the tank before removing it. Removal ■ Disconnect the power first. Cautions ■ Connect flanges with same dimensions. Cautions for ■ Make sure to insert washers between bolts and nuts to prevent loosening. -
Page 11: Failure Mode & Actions
You can request A/S at our website or by contacting our headquarters. ■ Headquarters ․ Factory ․ Laboratory Contact Number ADRESS: HITROL CO., LTD 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea T E L : 031-950-9700 (Headquarters & A/S) F A X : 031-943-5600 (Headquarters & A/S)
