HITROL HT-100R Series Instruction Manual

Float type level transmitter
Hide thumbs Also See for HT-100R Series:
Table of Contents

Advertisement

Quick Links

HT-100R Series
HITROL CO., LTD.
HEAD OFFICE.FACTORY.R&D INSTITUDE
HITROL CO.,LTD. 141, Palhakgol-gil, Jori-eup
Paju-si, Gyeonggi-do, Korea
TEL. : (00)-82-31-950-9700
FAX. : (00)-82-31-943-5600
www.hitrol.com
INSTRUCTION MANUAL
FLOAT TYPE LEVEL TRANSMITTER
HT-100R Series
Doc. no.: HT100R_IM_Eng_Rev.4
Issue date: 2020. 08
HITROL CO., LTD.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-100R Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HITROL HT-100R Series

Summary of Contents for HITROL HT-100R Series

  • Page 1 HT-100R Series HITROL CO., LTD. HEAD OFFICE.FACTORY.R&D INSTITUDE HITROL CO.,LTD. 141, Palhakgol-gil, Jori-eup Paju-si, Gyeonggi-do, Korea TEL. : (00)-82-31-950-9700 FAX. : (00)-82-31-943-5600 www.hitrol.com INSTRUCTION MANUAL FLOAT TYPE LEVEL TRANSMITTER HT-100R Series Doc. no.: HT100R_IM_Eng_Rev.4 Issue date: 2020. 08 HITROL CO., LTD.

  • Page 2: Table Of Contents

    Ex-proof Version · · · · · · · · · · · · · · · · · · · · · · · · · · 10 APPENDIX L · · · · · · · · · M-100R User Manual Flap Type Level Gauge with HT-100R Series · · · · 11 APPENDIX H · · · Serial USB Terminal Install Guide Maintenance ·...

  • Page 3: Overview

    HT-100R Series Overview HT-100R(-Ex) Series are FLOAT TYPE LEVEL TRANSMITTER that continuously measure water levels in containers using buoyancy. These transmitters can be easily installed and adjusted and can be used for chemicals because PVC and TEFLON are used on their detecting elements.

  • Page 4: Specifications

    HT-100R Series Specifications STAINLESS STEEL Model HT-100RS HT-100RSH HT-100RS-Ex HT-100RSH-Ex Mounting Flange Process Temperature Max. 80℃ Max. 150℃ Max. 80℃ Max. 150℃ Process Pressure Up to 20kg/cm2(300#) Power Source DC +24V Output DC 4~20mA(2~wire) Enclosure Weather-Proof (IP65) Ex-Proof (Ex d IIC T6)

  • Page 5: Float Application

    HT-100R Series Float Environment Application Float Temperature Pressure Acid Alkaline Solvent Liquid gas (℃) (㎏/㎠) SUS 316L -20 ~ +150 Up to 20 △ ○ ○ ◎ △ -10 ~ +60 ○ ○ △ TEFLON -20 ~ +150 0.5~3 ◎...

  • Page 6: Section Distance

    HT-100R Series Section Distance Distance(mm) Section 2" 3" 4" 50 (SUS, TEFLON) 100 (PVC) 250~5000(*) 50 (SUS) 70 (TEFLON) 100 (PVC) A = Upper Dead Band; Minimum length which cannot be measured from the bottom of flange B = Measuring Range; It can be different according to the material.

  • Page 7: Float Specifications

    HT-100R Series Float Application Table Dimensions (mm) Guide Product Size Material S.G Range Tube Ф49 Ф15.5 Ф12.7 316L 0.7~1.0 2" Ф50 Ф20 Ф15.8 0.6~0.9 Ф45 Ф15 Ф12.7 316L 0.7~1.1 Ф73 Ф23.5 Ф21.7 316L 1.0~1.5 3" Ф73 Ф23 Ф21.7 Titanium 0.6~0.9 HT-100RS Ф65...

  • Page 8: Product Composition

    HT-100R Series Product Composition Polycarbonate Housing Aluminum Housing Aluminum Housing Aluminum Housing Aluminum Housing MAX 80℃ MAX 80℃ MAX 150℃ MAX 80℃ MAX 150℃ Flange Flange Flange Flange 304, 316L 304, 316L 304, 316L, W/TEFLON Stopper Stopper Stopper Stopper 316L...

  • Page 9: Dimensions

    HT-100R Series Dimensions <WEATHER-PROOF Version> HT-100RS HT-100RV HT-100RT HT-100RSH HT-100RTH HITROL CO., LTD.

  • Page 10: Ex-Proof Version

    HT-100R Series <Ex-PROOF Version> HT-100RV-Ex HT-100RT-Ex HT-100RS-Ex HT-100RSH-Ex HT-100RTH-Ex HITROL CO., LTD.

  • Page 11: Flap Type Level Gauge With Ht-100R Series

    HT-100R Series FLAP TYPE LEVEL GAUGE with HT-100R Series HT-100R HT-100R+HLG-100F HT-100RH+HLG-100F HT-100R-Ex HT-100R-Ex+HLG-100F HT-100RH-Ex+HLG-100F HITROL CO., LTD.

  • Page 12: Maintenance

    HT-100R Series Maintenance The major parts of the HT-100R(-Ex) Series level transmitters to be inspected are divided into the sensor element and the transmission element. The sensor element consists of Reed Switch, Resistors, and the Float, and the transmission element is the M-100R(R/I CONVERTER). The life spans of major parts vary with user environments and can be used in optimum conditions through periodic inspections.

  • Page 13: Precautions For Removal

    HT-100R Series Precautions for - Check the level and presence of measurements in the tank before removing it. Removal - Wear gloves when removing it, to prevent a burn. - Disassemble work shall be done with the power off. - If there is explosive gas atmosphere, do not open the cover.

  • Page 14: Installation

    HT-100R Series Installation Below recommendation shall be considered when installation. The product may malfunction if the product has Protection tube shall be applied if there been installed at the inlet through which the is a flow or slopping of the medium in measure object flows in.

  • Page 15: Safety And Environment

    HT-100R Series Safety and ■ Precautions for Use Environment - Make sure to connect the product and vessel using required tools for sure. - Keep the lock key safe and make sure that it is locked. - Do not apply high impact to the product.

  • Page 16: User Training

    HT-100R Series User Training The above matters should be fully understood, and the temperature of fluids in the container where the product is used shall not exceed 80℃ in the case of general types and 150℃ in the case of high-temperature types. In addition, make sure that the ambient temperature of housing is kept at -20℃...

  • Page 17: Output Current Holding Phenomenon

    You can request A/S at our website or by contacting our headquarters. ■ Headquarters ․ Factory ․ Laboratory Contact Number ADRESS: HITROL CO., LTD 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea T E L : 031-950-9700 (Headquarters & A/S) F A X : 031-943-5600 (Headquarters & A/S)
  • Page 18 APPENDIX M HT-100R DISPLAY User Manual Float Type Level Transmitter Doc. no.: Rev0.0 Issue date: 2020.07.30...
  • Page 19 1. HT-100R Display Module Configuration & Function Configuration Function ■ Function setting S Key ■ Save the setting ■ Mode change M Key ■ Cancellation ■ Span Set ▲ Key ■ Setting the value left & up ■ Zero Set ▼...
  • Page 20 2. Specifications Items Specifications Model M-100RD (Compact), M-RIU (Local) Microprocessor 16Bit Microprocessor Current Loop Interface 2-Wire Loop Current Supply Voltage DC+17V ~ +40V @ Typ.+24V Output Current Accuracy 4.0mA ~ 20.0mA @ ±0.2% F.S Resolution ±10mm @ With Sensor ■ 3.8mA ~ 20.5mA @ Alarm 3.6mA, 21mA [NAMUR NE43] Output Current Range ■...
  • Page 21 3. Configuration of Setting Menu Content Description Remarks [00] Select Unit : mA / % : mA : % (※ Unit Setting for [02], [03]) [01] Select Level / Distance : Level : Distance Quick Menu Setting 0.0% ~ 95.0% or 4.000 mA ~ 19.200 mA (Float : Quick [02] Zero Setting...
  • Page 22 4. Setting and Operating Display Mode Whenever button is pressed, Display Mode is switched sequentially. ※ Rotation mode ( ) show each display mode automatically at interval of 1 second by default. It can be set up to 10 second at intervals of 0.5 seconds. □...
  • Page 23 □ How to select the Setting Menu Press Each Setting Menu can be switched by usage of arrow ( ) buttons. Press S button for 1 second to set of each function referring of below table. □ How to change the setting value Shift Digit Change Value “Flickering only one Digit”: It is available to shift to the other digit.
  • Page 24 ■ Definition of Height Criterion of Level: The direction in which the medium is raised based on the bottom of the tank. Zero Height: The height from bottom of tank to center of float at zero position. Span Height: The height from bottom of tank to center of float at span position.
  • Page 25 5. UART Monitoring ■ Monitoring Method □ You can check the setup and operation status using PC and Smartphone. □ The execution method is the same using PC and Smartphone. (Password: 1975) □ Run Screen Component: You can check the sensor measurement status, sensitivity setting value, relay setting, etc.
  • Page 26  mA / % Unit Set  Level / Distance Set  Zero Setting  Span Setting  Zero Height Setting (Criterion of Level)  Span Height Setting (Criterion of Level)  Tank Height Setting (Criterion of Level)  Auto Set Input ...
  • Page 27 ■ Monitoring Method Using Smartphone □ Component: Smartphone(Android OS), OTG, USB Cable(typical USB to Micro USB B), UART ADAPTOR. □ App: Refer to “Serial USB Terminal Install & Setting Guide” [USB Cable] [M-100RD Smartphone UART Component] [Enter PW and Fly command] [Home Screen] [Select UART Connection] [Run Screen]...
  • Page 28 ※ Caution: If wrong setting, Yellow LED will be flickering and 3.6mA current will be out. ■ Auto Setting (Applied to HT-100R Series Only.) In case the M-100R to be replaced without separation of the sensor from the tank, set it as below.
  • Page 29 ■ Offset Adjust as below when fine adjustment is required or there is an error of the measuring device. Step. 1 Step. 2 Step. 3 ▷Span◁ 또는 Hold down button and adjust a current output finely using button. ▷Zero◁ 또는 Press buttons at once for Press...
  • Page 30 APPENDIX H Serial USB Terminal Serial USB Terminal Install & Setting Guide Application : Level Switch / Level Transmitter Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 31 ■ Installing Serial USB Terminal App □ Search and Install a App that "Serial USB terminal" in the App Store. ■ Serial USB Terminal Setting □ Run The Serial USB Terminal Icon □ Four types of environments must be set up for normal operation of Serial USB Terminal. ▶...
  • Page 32 ■ Serial – Baud rate Setting □ Baud rate : 19200 -> 9600 [Complete] [Select Baud rate] [Setting] [Default] ■ Terminal - Show connection message / Show timestamps Setting □ Show connection message : ON -> OFF □ Show timestamps : ON -> OFF □...
  • Page 33 ■ Receive – Newline Setting □ Newline : CR+LF (Carriage Return + Line Feed) Check [Default] ■ Send - Newline Setting □ Newline : Auto(same as Receive) -> CR [Select Newline] [Default] [Setting] [Complete] Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 34 ■ Send - Character delay Setting □ Character delay : 0ms -> 5ms [Complete] [Setting] [Default] [Select Character delay] ■ Send – Local echo / Clear input on send Setting □ Local echo : ON -> OFF □ Clear input on send : OFF -> ON [Complete] [Complete] [Select Local echo]...
