RCS

Communicating Thermostat

Installation and Operation Manual

Model

TZ40 Thermostat

TS40 Wall Display Unit

HFR HVAC Control Unit

DO NOT USE THIS PRODUCT FOR BUILDING FREEZE PROTECTION! YOU ARE ADVISED TO

INSTALL A MECHANICAL FREEZE PROTECTION DEVICE ON YOUR SYSTEM FOR THIS PURPOSE.

Model TZ40

with ZWave Communications

Rev P HVAC Control Unit

DCN: 141-00885

Revision 16

Date: 1/26/06

This manual applies to these TZ40 Revisions or later

Rev

Part Number

001-00885

001-01060-26

001-01430-01

*** IMPORTANT NOTICE ***

Residential Control Systems Inc.

Firmware Version

3.07.4

3.05.2

Need help?

Do you have a question about the TZ40 and is the answer not in the manual?

Questions and answers

Summary of Contents for RCS TZ40

Page 1 Communicating Thermostat with ZWave Communications Installation and Operation Manual Rev P HVAC Control Unit DCN: 141-00885 Revision 16 Date: 1/26/06 This manual applies to these TZ40 Revisions or later Model Part Number Firmware Version TZ40 Thermostat 001-00885 TS40 Wall Display Unit 001-01060-26 3.07.4...
Page 2 Settings, and Thermostat Info. Others may be present and selectable from the menu button in special versions of the WDU. The TZ40’s LCD features a backlit display for low light and night visibility. It can be set to remain on constant or to turn out after a 20-45 second delay.
Page 3 This makes an intuitive and easy to use “user interface”. It allows the many functions of the TZ40 to be easily navigated. The TS40’s main screen is the Thermostat Control Screen. From this screen you can access a menu screen that will list other control screens or setup screens.
Page 4 The outside temperature is displayed in the top center of the main screen, if outside temperature information has been sent to the thermostat or a remote outside temperature sensor is connected to the WDU. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 5 § Heat § Cool § Auto § Off Mode: System is off. No heating or cooling will come on. If it was on, the system will turn off. Heat Mode: Only heating will occur. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 6 There is also an AWAY mode that you can select if you press and hold the button for 3 seconds. In the Away mode, preset Heating and Cooling setpoints are used. Run Button AUTO § MENU MODE § Hold § Away (Press and hold button) DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 7 . Momentary display of “Communications Failure” caused by loss of data, will clear automatically when data communication is restored. If the “Communications Failure” display stays on, check wiring or control unit for problems. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 8 User Settings Thermostat Info Select Done Screen navigation buttons: Done Return to Thermostat Screen Move menu selection pointer up Not used Not used Move menu selection pointer down Select Select menu item at pointer DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 9 LED and icon will stay on. Messages are entered as most recent message as number 1 message. Message Screen Messages Message 1 10/14 5:35 PM The TZ40 can receive 16 text messages, each up to 80 characters long. They are date/timed stamped. Done Prev Next Screen navigation buttons: When you first select the Message Screen, the most recently received message will be displayed as Message 1.
Page 10 Groups of days can be copied with the same schedule. When the TZ40 is set to “Run” mode, the schedule will be executed daily, with the setpoints being changed as per that days schedule stored in the thermostat. “Hold” mode stops schedule operation and holds the current setpoints until changed manually or by network commands.
Page 11 Return to Main Menu Screen + Increment time or temperature Scroll Back Scroll Forward - Decrement time or temperature Select the next Day schedule Next OR if the copy “c” is selected, go to Copy copy schedule screen. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 12 Return to Schedule Screen Yes - Copy schedule to this day Move back with selection bar Move forward with selection bar No - Do not copy to this day Copy the schedule to the selected days Copy DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 13 Screen Timeout F/C Mode Sensor Calibration Select Done Done Return to Main Menu Move menu selection pointer up Increment value Decrement value Move menu selection pointer down Select the function to be set Select DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 14 DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 15 Back Cancel and return to User Settings Menu + Increment selected item Move back with selection box Move forward with selection box Decrement selected item Set the time and return to User Settings Menu DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 16 Main Menu > User Settings > Sensor Calibration The Sensor Calibration screen allows you to change the temperature calibration for the internal and any external remote temperature sensors attached to the TZ40 WDU. You can change the temperature calibration by +/- 7 degrees.
Page 17 Backlite Timeout ON Level 100% OFF Level Contrast Select Done Screen Navigation Buttons Done Return to User Settings menu Move menu selection pointer up Increment value Decrement value Move menu selection pointer down Not used DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 18 Thermostat Info Screen Thermostat Info TS40R Ver: 03.07.4 HFR Ver: 03.05.2 System Type: Standard Fan Type: No Fan w/HT Network Address: Done Screen navigation buttons: Return to Main Menu screen. Done DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 19 Same for setting the heating setpoint above the cooling setpoint will PUSH the cooling setpoint up to maintain this separation. Range is 3 to 15 degrees. Default set to 4 degrees. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 20 INSTALLER SETTINGS CAUTION! Do not change these settings unless you are sure of the effect these changes will make. Changing the network address will make the thermostat not respond if the address is incorrect. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 21 Move menu selection pointer up Increase by 1 or change from Y to N Decrease by 1 or change from Y to N Move menu selection pointer down Select Select menu item to go to a submenu DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 22 TZ40 Installation STOP Before proceeding with removing an existing thermostat and installing the TZ40, Read the following important steps. 1. Record existing wiring information on the enclosed wiring form. 2. Perform the TZ40 bench test 3. Check WDU wiring BEFORE applying power to control unit.
Page 23 Model TS40 WDU has an remote sensor connector, J2, on the WDU base for connection of an external remote temperature sensor. Follow the wiring diagram with the remote sensor to connect to the WDU. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 24 HVAC system but care should be taken to avoid the hot burner section or high vibration areas. Control unit wiring The TZ40 HVAC Control Unit is connected to the HVAC system and to the Wall Display Unit as well as the serial communications and power connections. Control Unit to WDU wiring Connect the WDU to the Control Unit with existing thermostat wiring in retrofit installations.
Page 25 Gas furnaces do not require fan outputs for heating calls. Set SW1-2 to the Off - to the left. (default) b. Electric furnaces do require fan outputs for heating calls. Set SW1-2 to the On - to the right. DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 26 2. Set SW1-2 (position 2) to the correct changeover (reversing valve) setting for your Heat Pump system. a. For systems with changeover with cooling, Set SW1-2 to Off - to the left (default setting) b. For systems with changeover with heating, Set SW1-2 to On - to the right DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
Page 27 TZ40 Power Connection The TZ40 Control Unit requires 24VAC power from the HVAC system it is controlling. Connect the 24VAC Common (Blue wire/terminal) and 24VAC R (Red wire/terminal) from the HVAC system to the control unit’s HVAC System terminal block J4’s 24VCom and 24V RH or 24V RC terminals (the RH and RC terminals are default jumpered together…see below)
Page 28 2. Connect the ZWB to the TZ40 HVAC control unit with 22-24Ga wiring. (Category 3-5 wiring acceptable). Wiring can be up to 1000ft. 3. Connect the D+, D- and Gnd terminals on the ZWB module to the RS485 connection on the TZ40 control unit.
Page 29 System Checkout It is strongly recommended that you hook-up and run a simple bench test before installing the TZ40. Not only will this save you time in system checkout but will also familiarize you with the thermostat’s operation. THERMOSTAT BENCH TEST 1.
Page 30 (O) outputs. You must know what your system CO type is (CO with Cool (typical) or CO with Heat). You should have configured the TZ40 control unit for correct CO type, refer to this setting. Heat Pump systems have an additional O terminal.
Page 31 If S1 is set to On for HP HVAC systems, then S2 selects the changeover or reversing valve type. Set S2 to OFF for changeover with cooling (default setting). Set S2 to ON for changeover with heating DCN: 141-00885-16 1/26/06 TZ40 Thermostat Manual...
