RCS OneHome TS40 Integration Note

Hide thumbs Also See for OneHome TS40:

Advertisement

Quick Links

OneHome™
Management and Control Solutions
Manufacturer:
Model Number(s):
Comments:
Document Revision Date:
O
VERVIEW AND SUPPORTED
The RCS TR16 and TR40 are retrofit-able RS-485 communicating thermostats that use a 2-piece
installation method to leverage existing HVAC wiring for easy install. Each thermostat consists of two
parts: a wall display unit, which resembles a typical thermostat; and a HVAC Control unit. The WDU is
installed using existing HVAC wires at the desired location, and connected to the HVAC Unit back box via
the existing 4-wire run. All new wire connections can then be made the HVAC unit without running new
wires to each thermostat location. The TR16/TR40 thermostats support 2-stage heat/2-stage cooling in a
conventional gas or electric install, and 3-stage heat/2-stage cool in a heat pump setup. The TS16 and
TS40 are variants of the TR16/TR40 that can be used with an HVAC Zone Controller that adds
independent zone control via the use of associated dampers for improved efficiency and distribution. See
RCS for full details.
Independent TR16/TR40 installs, and installs using the TS16/TS40 with ZCV series zone controllers are
compatible with external RS-485 or RS-232 control from HomeLogic, and provide reliable two-way control
and feedback.
RCS T
HERMOSTATS SUPPORT THE FOLLOWING FEATURES
Temperature Control: Temperature control can be managed by schedules tied to house modes or by
manual control based on time (Timed Temporary Hold, Temporary Hold and Permanent Hold).
Mode Control: The climate system can be set to run in the following heating and cooling modes: Heat
only, Cool only, Auto Heat Cool (TR40 only) or Off. In addition, systems that have a fan can be set to
run in Automatic mode or Continuous mode.
History View: The history view shows the inside temperature, outside temperature, unit run and fan run
times, and cooling and heating setpoints.
Schedule Control: Multiple schedules may be set up, and are automatically tied to the house mode.
Zone Control: Multi-zone "Smart Damper/Vent" systems using the RCS ZCV series of zone controllers
are compatible with HomeLogic.
Remote Sensors: Outside Temperature can be read from RCS climate systems.
RCS T
DO NOT
HERMOSTATS
Mode Control: Auto Heat Cool is not available for external control on the TR16 thermostats.
Message Features: Message features supported by RCS for display of text based messages on the
WDU readout are not supported in HomeLogic.
Humidity: No humidity features or sensors are supported with RCS climate systems.
Note: The TS16 and TS40 are equivalent models to the TR16 and TR40, sold for use with Zoned
Systems. They do not include the HVAC controller hardware, as this is part of the ZCV Series controller.
HomeLogic LLC ●
RCS
TR/TS40, TR/TS16 Thermostat
HomeLogic Core Module 4.0 Build 1583 or later required
10/30/2009
F
EATURES
SUPPORT THE FOLLOWING FEATURES
100 Hoods Lane
Marblehead, MA 09145
Climate Integration Note
:
:
Phone (781) 639-5155
Fax (781) 639-9677

Advertisement

loading
Need help?

Need help?

Do you have a question about the OneHome TS40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RCS OneHome TS40

  • Page 1 SUPPORT THE FOLLOWING FEATURES Mode Control: Auto Heat Cool is not available for external control on the TR16 thermostats. Message Features: Message features supported by RCS for display of text based messages on the WDU readout are not supported in HomeLogic.
  • Page 2 3. Run Cat5 or 18/4 cable from the Control Units to the Wiring Hub, and run appropriate control cable from the Control Units to the heating and cooling equipment. Consult the HVAC equipment/RCS documentation for cabling requirements.
  • Page 3 Terminal Strip 1 2 VDC P o wer Supply Vario us (See No te) Terminal Strip Calculate amperage required befo re purchase. See RCS do cs. Wiring Hub 485P B RS-485 X RS-232 Terminal Strip/DB 9 Female Use the 485P B fo r sho rt wire runs fo r 1 - 2 Thermo stats...
  • Page 4 1: D 485PB W IRING IAGRAM ETAIL OF IRING Note: Per RCS Documentation, the 485PB unit is intended for 1 or 2 thermostats with short wiring runs. For larger jobs, use the 8AH485D: see below for wiring diagrams. 4 of 10...
  • Page 5 4. 8AH485D is a star wiring topology board. No termination is required if wiring a single stat to a single connector. If you have mulit-drop connection behind a terminal, follow standard termination procedures. See RCS documentation for details. 2B: D...
  • Page 6 1 8-2 Cable Terminal Strip 24VA C P o wer Supply Vario us (See No te) Terminal Strip Calculate amperage required befo re purchase. See RCS do cs. HA-CB-307 DB9M- -RJ45F ( OME WIRING CONFIGURATIONS MAY ALSO REQUIRE STRAIGHT THRU ADAPTERS...
  • Page 7 3: D HVAC C IRING IAGRAM ETAIL OF ONED ONTROL YSTEM 7 of 10...
  • Page 8 Once the thermostats are powered up and running properly, you need to make a few changes to the thermostat settings to integrate with HomeLogic. Other than the changes listed below, follow standard RCS programming procedures: all TStats and Zone Controllers must be properly configured for standalone operation prior to integration in HomeLogic.
  • Page 9 Notes: 1. The Communication Devices Name is set to Climate by default. After you select the RCS Thermostat Network, the name will change to RCS Thermostat Network. 2. You must enter the correct thermostat ID for each thermostat. IDs must start at 1, and increment sequentially without skipping numbers.
  • Page 10 Configurator. 3. Configuring 2 subsystems with the same serial port. 4. Incorrect serial type setting. The RCS Thermostat Network Communication Device has a drop down for RS-232 or RS-485. Set this appropriately. RS-485 connections should be set to RS-485 Half Duplex, RS-232 connections should be set to RS-232.
