- Page 1 EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler...
- Page 2 EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler...
-
Page 3: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 4: Safety Precautions
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ............... 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................2 6. OPERATION CONTROLS AND FUNCTIONS ......3 6.1 Front Panel ................. 3 6.2 Rear Panel ................ -
Page 6: Introduction
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 1. INTRODUCTION This is a compact yet versatile 4K UHD HDMI and PC/HD to HDMI Scaler. It accepts a wide range of resolutions from 480i up to 1080p/WUXGA for PC/HD and up to 4K@60Hz (4:4:4) for HDMI with the ability to scale the output to a selectable resolution up to 4K@60Hz (4:4:4) with simultaneous de-embedded, digital optical and analog audio output. -
Page 7: Features
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 5. FEATURES • HDMI 2.0 with 4K@60Hz (4:2:0 and 4:4:4) support, DVI 1.0 compliant • HDCP 2.2 compliant • Supports PC input resolutions from VGA~WUXGA and HD input resolutions from 480i~1080p@60Hz • Supports HDMI input resolutions from 480i~4K@60Hz (4:4:4, 8-bit) •... -
Page 8: Operation Controls And Functions
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel OPTICAL OUT: Connect to powered speakers or an amplifier for digital audio output using an appropriate optical cable. Supports LPCM 2.0 audio only. Bitstream formats will be muted. -
Page 9: Rear Panel
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 6.2 Rear Panel PC IN: Connect to VGA source equipment such as a PC or laptop. YUV sources, such as DVD players, are also supported with the use of a 15-pin to 3-RCA adapter. HDMI IN: Connect to HDMI source equipment such as a media player, game console or set-top box. - Page 10 EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler V-POSITION 0~100 EXIT 0~100 GREEN 0~100 COLOR BLUE 0~100 EXIT PC/YPbPr SOURCE HDMI HDMI 640×480@60 800×600@60 1024×768@60 1280×768@60 1360×768@60 1280×800@60 1280×1024@60 1440×900@60 1400×1050@60 1680×1050@60 1600×1200@60 1920×1200@60 (RB) 480P@60 OUTPUT RESOLUTION* NATIVE 576P@50 720P@50 720P@60 1080P@50...
- Page 11 EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler FULL OVER SCAN UNDER SCAN SIZE* BEST FIT LETTER BOX PAN SCAN BEST FIT EXIT AUTOMATIC EMBEDDED HDMI INPUT AUTOMATIC ANALOG OPTICAL AUDIO ANALOG PC INPUT ANALOG OPTICAL VOLUME [Analog 0~100 100 [=2Vrms] audio only]...
-
Page 12: Connection Diagram
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler EXIT RESET FACTORY EXIT Note: • When outputting a 4K resolution with the same refresh rate as the 4K source (or when bypass mode is enabled) the OSD items marked with an asterisk (*) will be disabled. -
Page 13: Specifications
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 8. SPECIFICATIONS 8.1 Technical Specifications Video Bandwidth 600MHz/18Gbps 1×HDMI, 1×VGA [15-pin D-sub], Input Ports 1×OpticalAudio, 1×3.5mm Audio Output Ports 1×HDMI, 1×Optical Audio, 1×3.5mm Audio 408i@60Hz - 4K@60Hz (4:4:4, 8-bit) Supported Resolutions VGA@60Hz - WUXGA@60Hz (RB) -
Page 14: Video Specifications
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 8.2 Video Specifications 8.2.1 Supported Resolutions PC Resolution (Hz) HDMI Input VGA Input HDMI Output 640×480@60/72/75/85 800×600@56/60/72/75/85 60Hz only 1024×768@60/70/75/85 1280×1024@60/75/85 1360×768@60 1280×800@60 ... -
Page 15: Scaled Resolutions
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 8.2.2 Scaled Resolutions UHD BYPASS SCALER BYPASS Input Resolution Output Resolution Bypass Scaler Bypass Scaler Path Path Path Path Non-4K Timing Any Timing 4K but not 24Hz 4K@24Hz 4K but not 25Hz 4K@25Hz ... - Page 16 EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler Sampling Rates (kHz) HDMI Optical 44.1 88.2 176.4 Input Output Frequency Frequency Level Level THD+N Crosstalk Range Response Digital Audio Digital Audio 0 dB ~ -1...
-
Page 17: Acronyms
EGE-SCA-6UHD-HVG HDMI/VGA to HDMI Scaler 9. ACRONYMS ACRONYM COMPLETE TERM Decibel EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface LPCM Linear Pulse-Code Modulation Signal-to-Noise Ratio THD+H Total Harmonic Distortion plus Noise Ultra-High-Definition Video Graphics Array... - Page 19 www.geratech.eu...
