- Page 1 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER...
- Page 2 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER...
-
Page 3: Copyright Notice
The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document. -
Page 4: Safety Precautions
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ............... 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................2 6. OPERATION CONTROLS AND FUNCTIONS ......2 6.1 Front Panel ................. 2 6.2 Rear Panel ................ -
Page 6: Introduction
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 1. INTRODUCTION This multi-format scaler features the three most popular input interfaces utilized on source devices: HDMI, DisplayPort and VGA. This unit is an ideal solution for use in conference rooms and showrooms and for any customer who has a requirement to match disparate input sources to the native resolution of a display. -
Page 7: Features
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 5. FEATURES • Multiple input formats including HDMI, DisplayPort and VGA • HDMI 2.0, HDCP 2.2, HDCP 1.4 and DVI 1.0 compliant • Supports video timings up to 4K@60Hz YUV 4:4:4 over the HDMI and DisplayPort inputs and over the HDMI output •... -
Page 8: Rear Panel
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER HDMI: When the selected input source is HDMI this LED will illuminate solid green. VGA: When the selected input source is VGA this LED will illuminate solid green. The following hotkey functions are also available: 1. -
Page 9: Webgui
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER DC 5V: Plug the 5V DC power adapter into the unit and connect it to an AC wall outlet for power. 6.3 WebGUI Install the IP Discovery Tool: (1) Please obtain the Device Discovery software from your authorized dealer and save it in a directory where you can easily find it. -
Page 10: Webgui Control Page
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.3.1 WebGUI Control Page All functions, including power, 4KUHD Bypass input selection, EDID management, HDCP management, output adjustments, OSD settings, Ethernet settings, volume adjustments, and reset/firmware functions, are presented on a single web page to allow for intuitive operation. -
Page 11: Uhd 4K Bypass
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.3.3 UHD 4K Bypass The UHD 4K bypass input is able to be selected bypass or down scale. Please select the bypass "On" to remain 4K UHD input or "Off" for down scale. 6.3.4 Input Source Selection and Auto Source Detection (a) Source: The input source can be selected here. -
Page 12: Edid & Hdcp Settings
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.3.5 EDID & HDCP Settings (a) EDID: Four EDID options are available: Internal 4K2K, Internal 1080p, External TV (EDID is copied from the connected display device) and External TV+2ch (EDID is copied from the connected display device but the audio is set to LPCM 2.0). -
Page 13: Keep Ratio
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER (b) Aspect: The following output aspect ratios are available: FULL (expand the source to fill the output resolution regardless of the original aspect ratio), 16:9, 16:10, 4:3 and KEEP RATIO (maintain the aspect ratio of the source relative to the aspect of the output resolution). -
Page 14: Osd Settings
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.3.8 OSD Settings This tab allows for the control and adjustment of all available OSD (On Screen Display) settings. The OSD Information Display can be turned on or off. The display time for the Main Menu and Info Menu can be set with a range between 5 and 45 seconds, or they can be set to “infinite”... -
Page 15: Audio Settings
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.3.10 Audio Settings (a) Sound: This setting allows you to mute audio from the current input. (b) Volume: The audio volume can be adjusted from 0 to 100. 6.3.11 Reset Options This tab provides options for returning the Display, Audio, OSD and Ethernet settings to their individual factory defaults. -
Page 16: Telnet Control
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.4 Telnet Control Before attempting to use telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks. To access Telnet in Windows 7, click on the “Start” menu and type “cmd” in the search field, then press “Enter”. -
Page 17: Rs-232 Command List
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER This will connect us to the unit we wish to control. Type "help" or “?” to list the available commands. Note: Commands will not be executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly. - Page 18 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SET OUTPUT RESOLUTION!! SRES PARAM=(0~36). (0)=800X600P60,(1)=1024X768P60,(2)= 1280X800P60(3)= 1280X1024P60 (4)=1366X768P60,(5)=1400X1050P60,(6 )=1600X900P60 (7)=1600X1200P60,(8)=1680X1050P60,( 9)=1920X1200P (10)=1280X720P50,(11)=1280X720P59,( 12)=1280X72 0P60 (13)=1920X1080I50,(14)=1920X1080I59, (15)=1920X108 0I60 (16)=1920X1080P23,(17)=1920X1080P2 SRES 4,(18)=1920X108 0P25 (19)=1920X1080P29,(20)=1920X1080P3 0,(21)=1920X108 0P50 (22)=1920X1080P59,(23)=1920X1080P6 0,(24)=2048X108 0P23 (25)=2048X1080P24,(26)=3840X2160P2 3,(27)=3840X216 0P24 (28)=3840X2160P25,(29)=3840X2160P2 9,(30)=3840X216 0P30 (31)=3840X2160P50,(32)=3840X2160P5...
- Page 19 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SHOW CURRENT INPUT AUTO DETECT SOURCE RAUTOSCR STATUS!! RAUTOSCR NO PARAMETER!! SET CONTRAST VALUE!! SCON SCON PARAM PARAM(0~100) VALUE. SHOW CONTRAST CURRENT VALUE!! RCON RCON NO PARAMETER!! SET BRIGHTNESS VALUE!! SBRI SBRI PARAM PARAM=(0~100) VALUE.
- Page 20 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SET OSD VERTICAL POSITION!! SOSDV SOSDV PARAM ,PARAM=(0~100) SHOW OSD VERTICAL POSITION CURRENT!! ROSDV ROSDV NO PARAMETER!! SET OSD TRANSPARENT VALUE!! SOSDG SOSDG PARAM,PARAM=(0~7). SHOW OSD TRANSPARENT CURRENT VALUE!! ROSDG ROSDG NO PARAMETER!! SET OSD MAIN MENU DISPLAY TIME!! SOSDMT PARAM PARAM=(0~9) .
- Page 21 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SHOW STATIC CURRENT IP ADDRESS TO SCREEN!! RIPADD RIPADD NO PARAMETER!! SET STATIC SUBNET ADDRESS!! SMAADD SMAADD PARAM PARAM=xxx.xxx.xxx.xxx xxx=(0~255) SHOW STATIC CURRENT SUBNET ADDRESS TO SCREEN!! RMAADD RMAADD NO PARAMETER!! SET STATIC GATEWAY ADDRESS!!
- Page 22 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER SET HDCP OUTPUT!! SHDCP PARAM,PARAM=(0~2) SHDCP PARAM(0)=HDCP ENABLE. (1)=HDCP FOLLOW OUT. (2)=HDCP DISABLE. SHOW OUTPUT HDCP CURRENT!! RHDCP RHDCP NO PARAMETER!! SET NWE FIRMWARE TO UNIT!! SUPFW SUPFW NO PARAMETER!! RESET THE UNIT TO FACTORY...
-
Page 23: Osd (On Screen Display) Menu
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.6 OSD Menu SECOND LEVEL ADJUSTABLE FIRST LEVEL PARAMETERS AND DEFAULT SETTINGS 800x600P60 1024X768P60 1280X800P60 1280X1024P60 1366X768P60 1400X1050P60 1600X900P60RB 1680X1050P60 1600X1200P60 Output 1280X720P50/59/60 1280X720P60 Resolution 1920x1200PRB 1920X1080I50/59/60 1920X1080P 23/24/25/29/30/50/59/60 2048X1080P23/24 3840X216 0P23/24/25/29/30/50/59/60 4096X2160P23/24 NATIVE Input UHD4K On / Off Select on or off. - Page 24 EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER Aspect Full Select ON or OFF, default is ON Aspect 16:9 Select ON or OFF, default is OFF Aspect Settings Aspect 16:10 Select ON or OFF, default is OFF Aspect 4:3 Select ON or OFF, default is OFF...
-
Page 25: Remote Control Unit
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER Source Info: Type Name Model Sink Info: Information Type Model Native1 Native2 HDCP Out Note: In the following scenarios deep color will be kept from the input source. Input timing: 3840X2160P/23 & output timing: 3840X2160P/23 Input timing: 3840X2160P/24 &... -
Page 26: D-Sub 9 Pin Definition
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 6.8 D-sub 9 Pin Definition Define TX / RX TxD/RxD RxD/TxD Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1... -
Page 27: Connection Diagram
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 7. CONNECTION DIAGRAM... -
Page 28: Specifications
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 8. SPECIFICATIONS 8.1 Technical Specifications 1x HDMI 1x VGA Input Ports 1x DisplayPort 1x audio in 1x HDMI out Output Ports 1x audio out) 1x RS-232 Control Interfaces 1x Service (USB 2.0) 1x Control Up to 4K@60Hz for HDMI & DP input and... -
Page 29: Output Timing
EGE-SCA-6UHD-HVGDP HDMI/VGA/DP to HDMI SCALER 1400x1050/60/75 √ √ 1440x900/60/75 √ √ 1600x900/60 √ √(RB) 1600x1200/60 √ √ 1680x1050/60 √ √ 1920x1200/60RB √ √ 3840x2160/24/25/30 √ 3840x2160/50/60(4:2:0) √ 4096x2160/50/60 √ √ OUTPUT TIMING HDMI 800x600/60 √ 1024X768/60 √ 1280X800/60 √ 1280X720P/50/59/60 √... - Page 31 www.geratech.eu...
