geratech EGE-SP118-4K6 Manual

18gbps 1×8 hdmi splitter
Hide thumbs

Advertisement

Table of Contents

EGE-SP118-4K6
18Gbps 1×8 HDMI
Splitter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-SP118-4K6 and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-SP118-4K6

Summary of Contents for geratech EGE-SP118-4K6

  • Page 1 EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter...
  • Page 2 EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter...

  • Page 3: Table Of Contents

    EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 4: Introduction

    EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter 1. Introduction 18Gbps 1x8 HDMI Splitter is an advanced solution for splitting single HDMI signal to 8 HDMI outputs synchronously. It supports up to 18Gbps bandwidth, HDMI 2.0b/HDCP 2.2 content up to 4K@60Hz 4:4:4. It can be set the COPY/ AUTO EDID configuration.

  • Page 5: Operation Controls And Functions

    EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter Output Ports 8×HDMI Type A (19-pin female) Mechanical Housing Metal Enclosure Color Black Dimensions 243mm (W) × 102mm (D) × 16mm (H) Weight 572g Power Supply Input: AC100 - 240V 50/60Hz, Output: DC 12V/1A (US/EU standards, CE/FCC/UL certified) Power Consumption 6.15W (Max.)

  • Page 6: Application Example

    EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter When dial switch is dialled the ‘COPY’ position, the unit will read the EDID setting of the HDMI OUT 1 display device to source deveice, the source deveice will send again matching the OUT 1 display EDID device signal to all HDMI outputs.

  • Page 7: Faq

    EGE-SP118-4K6 18Gbps 1×8 HDMI Splitter 7. FAQ 1. Q: Where is this product usually used? A: It can be used in many place such as Entertainment Room / Home Theater / Lecture Room / Hall Presentation / Show Room / Demo Room / Public Commercial Display etc.
  • Page 9 www.geratech.eu...
