- Page 1 EGE-12VS 1×2 HDMI 4K2K Video Scaler...
- Page 2 EGE-12VS 1×2 HDMI 4K2K Video Scaler...
- Page 3 Geratech Technology assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
- Page 4 EGE-12VS 1×2 HDMI 4K2K Video Scaler SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-12VS 1×2 HDMI 4K2K Video Scaler CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ............... 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................1 6. OPERATION CONTROLS AND FUNCTIONS ......2 6.1 Front Panel ................. 2 6.2 Rear Panel ................ -
Page 6: Introduction
EGE-12VS 1×2 HDMI 4K2K Video Scaler 1. INTRODUCTION This HDMI Scaler is designed to scale 4K (and non-4K) HDMI signals to resolutions of 1080p/WUXGA or lower while also simultaneously bypassing the 4K signal to a 4K native display. With its friendly and simple OSD (On Screen Display) interface design this unit allows the user to easily change output resolutions and related video settings directly from the front panel. -
Page 7: Operation Controls And Functions
EGE-12VS 1×2 HDMI 4K2K Video Scaler 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel RS-232: This port is reserved for factory use only. SERVICE 1: This port is reserved for factory use only. POWER LED: This LED will illuminate GREEN to indicate the unit is on and receiving power. -
Page 8: Osd Menu
EGE-12VS 1×2 HDMI 4K2K Video Scaler HDMI OUT/BYPASS: Connect to an HDMI display (TV/monitor) or amplifier to view the original, un-scaled, digital video and audio output from the connected source (up to 4K@60Hz, YUV 4:2:0) HDMI Input Scaled Output Bypass Output... - Page 9 EGE-12VS 1×2 HDMI 4K2K Video Scaler Full Over Scan Under Scan Size Letter Box Pan Scan Best Fit 480i@60 Output Setting 576i@50 480p@60 576p@50 720p@50 720p@60 1080i@50 1080i@60 1080p@50 1080p@60 640×480@60 Resolution 800×600@60 1024×768@60 1280×1024@60 1600×1200@60 1366×768@60 1680×1050@60 1920×1200@60 1280×800@60 1440×900@60...
-
Page 10: Connection Diagram
EGE-12VS 1×2 HDMI 4K2K Video Scaler H-Position 0~100 V-Position 0~100 Timer 5~100 Background 0~100 OSD Setting Info Display Exit Reset Factory Setting Exit Input Information Output Version Exit 7. CONNECTION DIAGRAM 7.1 Option 1: Upscale to 1080p... -
Page 11: Option 2: Downscale To 1080P
EGE-12VS 1×2 HDMI 4K2K Video Scaler 7.2 Option 2: Downscale to 1080p... -
Page 12: Specifications
EGE-12VS 1×2 HDMI 4K2K Video Scaler 8. SPECIFICATIONS 8.1 Technical Specifications Video Bandwidth 340MHz/10.2Gbps Input Ports 1×HDMI Output Ports 2×HDMI Control Interface 1×RS-232 (3.5mm) 10m (1080p@60Hz, 12-bit) 5m (4K@60Hz, 4:4:4, HDMI Cable Length 8-bit) Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified) -
Page 13: Video Specifications
EGE-12VS 1×2 HDMI 4K2K Video Scaler 8.2 Video Specifications Supported Resolution (Hz) Scaled Output 640×480@60 800×600@60 1024×768@60 1280×800@60 1280×1024@60 1366×768@60 1400×1050@60 1440×900@60 1600×900@60 1600×1200@60 1680×1050@60 1920×1200@60 (RB) 720×480i@60 ... - Page 15 www.geratech.eu...
