EGE-6UHD-HDB-SP118
18Gbps HDMI 1×8
HDBaseT Splitter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-6UHD-HDB-SP118 and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-6UHD-HDB-SP118

Summary of Contents for geratech EGE-6UHD-HDB-SP118

  • Page 1 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter...
  • Page 2 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter...

  • Page 3: Table Of Contents

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 4: Introduction

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter 1. Introduction This 18Gbps HDMI 1x8 HDBaseT Splitter can distribute 1 source signal to any 8 display devices. Support video resolution up to 4K2K@60Hz 4:4:4. It is designed with 1 HDMI loop output and 8 HDBaseT outputs. The HDMI signal transmission distance can be extended up to 120 meters at the resolution of 4K2K@60Hz, or 150 meters at 1080P@60Hz via a single CAT6/ 6a/7 cable.

  • Page 5: Specifications

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter 4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2/1.x Video Bandwidth 594MHz/18Gbps Video Resolution Up to 4k2k@60Hz 4:4:4 Color Depth 8-bit,10-bit,12-bit(1080p@60Hz) 8-bit (4K2K@60Hz YUV4:4:4) 8-bit,10-bit,12-bit(4K2K@60Hz YCbCr 4:2:2/4:2:0) Color Space RGB 4:4:4, YCbCr 4:4:4 / 4:2:2 / 4:2:0...

  • Page 6: Operation Controls And Functions

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Power Supply Input: AC100 - 240V 50/60Hz, Output: DC 24V/2.7A (US/EU standards, CE/FCC/UL certified) Power Consumption Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F...
  • Page 7 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Rear Panel Name Function Description EDID DIP Used to set EDID mode. Please refer to Section “6. EDID switch Mode” for details. Connect to a PC or control system via a 3-pin phoenix connector cable for three functions: 1, Firmware update;...

  • Page 8: Hdbaset Receiver

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Plug the DC 24V power supply into the unit and connect DC 24V the adaptor to an AC outlet. (Note: The transmitter can power the receiver via a CAT cable.) POWER Press this switch to power on/off the device.

  • Page 9: Ir Pin Definition

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter AUDIO Audio output port, connect to amplifer or speaker. Connect to the IR Receiver cable. The IR signal will send IR IN to the IR OUT port of the transmitter. Connect to the IR blaster cable, the IR signal is from IR IR OUT IN port of the transmitter.
  • Page 10 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter 10101 4K2K30Hz_444, Dolby/DTS 5.1 10100 4K2K30Hz_444, HD Audio 7.1 10011 4K2K60Hz_420, Stereo Audio 2.0 10010 4K2K60Hz_420, Dolby/DTS 5.1 10001 4K2K60Hz_420, HD Audio 7.1 10000 4K2K60Hz_444, Stereo Audio 2.0 01111 4K2K60Hz_444, Dolby/DTS 5.1 01110 4K2K60Hz_444, HD Audio 7.1 01101 01101 4K2K60Hz_444, Stereo Audio 2.0 HDR...

  • Page 11: Ascii Commands

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Power on System Power on/off the Initializing... device,z=0~1 s power z! s power 1! power on Initialization (z=0 power off, z=1 power Finished! FW version x.xx.xx power on/ r power! Get current power state...
  • Page 12 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Reset to factory defaults System s reset! Reset to factory defaults s reset! Initializing... Initialization Finished! FW version x.xx.xx Output Setting Set hdmi loop output stream Enable hdmi on/off loop out z=0~1 stream s hdmi...
  • Page 13 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter Enable hdbt output 1 stream s hdbt 1 Disable hdbt stream output 1 Set hdbt output y stream on/ s hdbt y stream off, y=0~4(0=all) z=0~1 enable stream z! s hdbt 0 Enable hdbt all...
  • Page 14 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter EDID Setting Set input EDID from default EDID z, z=1~27 1, 1080p,Stereo Audio 2.0 2, 1080p,Dolby/DTS 5.1 3, 1080p,HD Audio 7.1 4, 1080i,Stereo Audio 2.0 5, 1080i,Dolby/DTS 5.1 6, 1080i,HD Audio 7.1 7, 3D,Stereo Audio 2.0 8, 3D,Dolby/DTS 5.1...
  • Page 15 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter s edid user1 s edid user1 user1 EDID data: 00 Set user1 EDID data FF FF FF FF ff ff ff ff …. ! FF FF …. …! user1 EDID data : 00 r edid...
  • Page 16 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter RS-232 BYPASS Setting RS-232 Set RS-232 port connect to connect to s rs232 s rs232 HDBT out1 Receiver RS-232 HDBT OUT1 bypass bypass port, y=0~5( 0=all, RS-232 not hdbt y! hdbt y! connect 1~4= hdbt out 1~4 5=NC)

  • Page 17: Application Example

    EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter 8. Application Example The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 18 EGE-6UHD-HDB-SP118 18Gbps HDMI 1×8 HDBaseT Splitter...
  • Page 19 www.geratech.eu...
