Summary of Contents for geratech EGE-11CD
- Page 1 EGE-11CD HDMI Audio Extractor...
- Page 3 The information in this manual has been carefully checked and is believed to be accurate. Geratech Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech Technology assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
- Page 4 EGE-11CD HDMI Audio Extractor SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
EGE-11CD HDMI Audio Extractor CONTENTS 1. Introduction ................4 2. Applications ................4 3. Package Contents ..............4 4. System Requirements ............4 5. Features ................... 4 6. Operation Controls and Functions ........5 6.1 Top Panel ................5 6.2 Right Panel ................. 6 6.3 Left Panel ................ -
Page 6: Introduction
EGE-11CD HDMI Audio Extractor 1. INTRODUCTION The HDMI Audio Extractor allows you to extract audio signals from your HDMI source. When connecting to a TV or display you don’t always get the best audio, or in the case of a PC monitor, no audio at all. So with this Audio Extractor you can take your original HDMI audio signal and convert it to digital optical or analog Stereo (L/R) audio. -
Page 7: Operation Controls And Functions
EGE-11CD HDMI Audio Extractor 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Top Panel Power LED: The Power LED will illuminate in blue when the unit is connected to the power supply and switched on. Link LED: The Link LED will illuminate in green when both the source and the display are connected and have established a link. -
Page 8: Right Panel
EGE-11CD HDMI Audio Extractor 6.2 Right Panel TV/Bitstream/2CH LPCM: This switch allows users to select the source's audio EDID. TV Mode: Switch to TV mode for the HDMI source to output audio per the EDID of connected TV or AV receiver, supports up to LPCM 7.1 channels. -
Page 9: Front Panel
EGE-11CD HDMI Audio Extractor 6.4 Front Panel HDMI In: Connect to a source device such as a DVD/Blu-ray player with an HDMI cable. 6.5 Rear Panel HDMI Out: Connect to the display (TV/monitor) with an HDMI cable for video and audio signal output. -
Page 10: Connection Diagram
EGE-11CD HDMI Audio Extractor 7. CONNECTION DIAGRAM... -
Page 11: Specifications
EGE-11CD HDMI Audio Extractor 8. SPECIFICATIONS Input Port 1×HDMI HDMI Audio Sampling Rate Up to 192 kHz Optical Audio Sampling Rate Up to 48 kHz Output Ports 1×HDMI, 1×Optical,1×L/R HDMI Audio Format LPCM 2/5.1/7.1CH, Dolby 5.1, DTS 5.1, DD+, D-TrueHD & DTS-HD Optical Audio Format LPCM 2CH, Dolby 5.1 &... -
Page 12: Acronyms
EGE-11CD HDMI Audio Extractor 9. ACRONYMS ACRONYM COMPLETE TERM HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface... - Page 13 www.egerate.com...
