- Page 1 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output...
-
Page 2: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 3: Safety Precautions
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •... -
Page 4: Table Of Contents
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output CONTENTS 1. Introduction ................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ............1 5. Features ...................2 6. Operation Controls and Functions ........3 6.1 Front Panel ................3 6.2 Rear Panel ................4 6.3 OSD Menu ................5 7. -
Page 5: Introduction
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 1. INTRODUCTION The 1 by 2 UHD Scaler with Audio De-Embedded is designed to upscale 1080p signal into 4K2K 6G or downscale 4K2K 6G signal into 1080p with synchronized digital and analog audio output. Friendly and simple design that allow user with direct viewing on input HDMI content and OSD that ease user with output settings/selection. -
Page 6: Features
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 5. FEATURES • HDMI with 6G 4Kx2K supported and HDCP 2.2 compliant • Supports HDMI signal bypass on both outputs or upscale 1080p signal into 4K2K on output B and downscale 4K2K signal into 1080p on output A •... -
Page 7: Operation Controls And Functions
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel TEST POWER 4K2K SYNC MENU PATTERN ENTER – POWER LED: This LED will illuminate when the device is connected with power supply. 4K2K LED: This LED will illuminate when the input source contains 4K2K signal. -
Page 8: Rear Panel
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 6.2 Rear Panel AUDIO OUT DC 5V HDMI IN HDMI OUT SERVICE HDMI IN: This slot is to connect with source equipment such as PS3 or Blu-ray player. HDMI OUT: These slots are to connect with UHD display/TV for images display. Each output can be displaying with different timing and pattern and image. -
Page 9: Osd Menu
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 6.3 OSD Menu LEVEL LEVEL LEVEL LEVEL PASS THROUGH DOWN 1080P OUTPUT A INPUT 4K2K FIX 4K2K(420) FIX 8 BITS PASS THROUGH INPUT 1080P OUTPUT UP 4K2K UP 4K2K(420) OUTPUT B PASS THROUGH... - Page 10 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output LEVEL LEVEL LEVEL LEVEL MODE AUTO PATTERN AUTO TIMING WHITE COLOR RED COLOR GREEN COLOR TEST PATTERN BLUE COLOR PATTERN MEGENTA COLOR YELLOW COLOR CYAN COLOR COLOR BAR RAMP TOGGLE 720X480P@60 720X576P@50 1280X720P@50...
- Page 11 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output LEVEL LEVEL LEVEL LEVEL YES/NO 720X480P@60 720X576P@50 YES/NO 1280X720P@50 YES/NO 1280X720P@60 YES/NO 1920X1080P@50 YES/NO YES/NO 1920X1080P@60 AUTO TIMING SELECT NEXT PAGE 3840X2160P@24 YES/NO 3840X2160P@25 YES/NO 3840X2160P@30 YES/NO 4096X2160P@24 YES/NO 4096X2160P@25 YES/NO 4096X2160P@30 YES/NO...
- Page 12 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output LEVEL LEVEL LEVEL LEVEL 4096X2160P@24 4096X2160P@25 4096X2160P@30 3840X2160P@50 3840X2160P@60 4096X2160P@50 4096X2160P@60 10 SEC. 20 SEC. 30 SEC. 40 SEC. SWITCH TIME 50 SEC. 1 MIN. 2 MIN. TEST PATTERN 3 MIN. 5 MIN.
- Page 13 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output LEVEL LEVEL LEVEL LEVEL INFORMATION RESOLUTION OUTPUT A OUTPUT B OUTPUT A DISABLE/ENABLE HDCP OUTPUT B DISABLE/ENABLE FIRMWARE VERSION VX.XX FIRMWAR UPDATE FACTORY SETTING Default settings are in Italian bold font Note: When input timing is non-VESA standard, OSD may be disable. To enter into OSD...
- Page 14 EGE-6UHD-12VS 4K HDMI Scaler with Audio Output * 1 Input → Output 3840x2160@24 → 1920x1080p@24 3840x2160@25 → 1920x1080p@25 3840x2160@30 → 1920x1080p@30 3840x2160@50 → 1920x1080p@50 3840x2160@60 → 1920x1080p@60 4096x2160@24 → 1920x1080p@24 4096x2160@25 → 1920x1080p@25 4096x2160@30 → 1920x1080p@30 4096x2160@50 → 1920x1080p@50 4096x2160@60 → 1920x1080p@60 * 2 Input →...
-
Page 15: Connection Diagram
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI Input Power Supply AUDIO OUT DC 5V HDMI IN HDMI OUT SERVICE HDMI Analog Stereo Output Outputs Active Speakers Bypass or Downscaled Output Bypass or Upscaled Output 4K UHD→1080p... -
Page 16: Specifications
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 8. SPECIFICATIONS 8.1 Technical Specifications VideoBandwidth 600MHz/18G 1 x USB (Service only) Output ports 2 x HDMI 1 x R/L HDMI Cable Length 15 m@1080p/8-bit, 10 m@1080p/12-bit, 5 m@4K Power Supply 5V DC/2.6A (US/EU standards, CE/FCC/UL... -
Page 17: Video Supports Specification
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 8.2 Video Supports Specification DVI and HDMI Supported Input Output 640x480i@60 640x480p@60 720x480p@60 720x576i@50 720x576p@50 800x600@56/60/72/75/85 1024x768@60/70/75/85 1280x720p@50/60 ... -
Page 18: Audio Specifications
EGE-6UHD-12VS 4K HDMI Scaler with Audio Output 8.3 Audio Specifications Input Output Frequence Output THD+N Crosstalk Level Level/Freq Terminal Response HDMI HDMI 0dB~-1dB <0.01% ±1dB >80dB <-80dB 0dBFS 20、 Vrms±10% <0.1% ±3dB >70dB <-60dB 1K、20KHz... - Page 20 www.geratech.eu...
