- Page 1 EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio...
- Page 2 EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio...
-
Page 3: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 4: Safety Precautions
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •... -
Page 5: Table Of Contents
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio CONTENTS 1. Introduction ................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ............. 1 5. Features ..................1 6. Operation Controls And Functions ........2 6.1 Front Panel ................2 6.2 Rear Panel ................ -
Page 6: Introduction
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio 1. INTRODUCTION The DVI to SDI Converter allows DVI-D signals to be shown on SDI display while ensuring high bit rates of 2.970 Gbit/s to give you high resolution signal without any loss. For professionals this means that it is now easier to convert your high definition DVI signal with audio to SDI for long distance transmission and display your work on SDI display. -
Page 7: Operation Controls And Functions
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel AUDIO IN: Connect to the audio source equipment (such as DVD player) with a 3.5 mm phone jack for audio signal input. AUDIO SW: This switch allows the user to choose between audio sources. Switch between the external (EXT) audio input (3.5 mm phone jack) or the internal (INT) audio... -
Page 8: Rear Panel
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio 6.2 Rear Panel DC 5V SDI OUT POWER LOCK DC 5V: Plug the 5 V DC power supply into the unit and connect the adaptor to AC wall outlet. POWER LED: This blue LED will illuminate when the device is connected to the power supply. -
Page 9: Connection Diagram
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio 8. SPECIFICATIONS Video Bandwidth 225 MHz/6.75Gbps Input 1×DVI, 1×3.5 mm Phone Jack Output 1×BNC (SD/HD/3G-SDI) DVI Timing Support 480i@59.94, 576i, 720p@50/59.94/60 1080i@50/59.94/60 1080p@23.98/24/25/29.97/30/50/59.94/60 SDI Timing Support SD-SDI: SMPTE 259M-C, 270 Mbit/s HD-SDI: SMPTE 292M, 1.485 &... -
Page 10: Acronyms
EGE-CNV-DVI-3SDIA DVI to 3G-SDI Video Converter with Audio 9. ACRONYMS ACRONYM COMPLETE TERM Bandwidth 2.94 Gbps ≈ 3G Serial Digital Interface... - Page 12 www.geratech.eu...
