- Page 1 EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX)
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) CONTENTS 1. Introduction ................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ...............1 5. Features..................2 6. Operation Controls and Functions ..........3 6.1 Front Panel ................3... -
Page 6: Introduction
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 1. INTRODUCTION The HDMI over HDMI and CAT5e/6/7 Splitter can split and distribute a single HDMI input and 2-way IR control to up to three CAT5e/6/7 outputs and includes a simultaneous HDMI bypass output. -
Page 7: Features
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant • Simultaneous HDMI and CAT5e/6/7 outputs • Supports data rate from 250Mbps up to 3Gbps •... -
Page 8: Operation Controls And Functions
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel DC 24V SYNC LINK EDID SERVICE HDMI IN HDMI OUT POWER HDMI IN: Connect with source equipment such as DVD/Blu-ray or PS3 player. -
Page 9: Rear Panel
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 6.2 Rear Panel CAT5e / 6 / 7 OUT IR IN IR OUT MODE LINK MODE LINK MODE LINK IR IN: Connect with IR Extender to receive IR signal from Transmitter side and blast out at Receiver side. -
Page 10: Connection Diagram
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 7. CONNECTION DIAGRAM 3D TV/Display Blu-ray or PS3 Player HDMI HDMI DC 24V SYNC LINK EDID SERVICE HDMI IN HDMI OUT POWER CAT5e / 6 / 7 OUT... -
Page 11: Specifications
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 8. SPECIFICATIONS Video Bandwidth 340Mbps/10.2Gbps Input ports 1 x HDMI, 1 x IR IN, 1 x USB (Service only) Output ports 1 x HDMI,... -
Page 12: Cat5E/6/7 Cable Specification
EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX) 8.1 CAT5e/6/7 Cable Specification Cable Range Pixel clock Video Data Supported Video Type rate Rate CAT5e/6/7 60 m <=225 MHz <=5.3 Gbps Up to 1080p, 60 Hz,... - Page 13 EGE-UHD-4HDB-1431L 1×4 HDMI over 1 HDMI and 3 CAT5e/6/7 Splitter, 60m with IR,PoC, Light Version(not include 507RX)
