Summary of Contents for geratech EGE-DVI-142DL-144DL
- Page 1 EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter...
- Page 2 EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter...
-
Page 3: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 4: Safety Precautions
EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •... - Page 5 EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter CONTENTS 1. Introduction ................1 2. Applications .................1 3. Package Contents ...............1 4. System Requirements ............1 5. Features................1 6. Operation Controls and Functions ........2 6.1 Front Panel ..............2 6.2 Rear Panel................2 7. Connection and Installation ..........3 8.
-
Page 6: Package Contents
EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter 1. INTRODUCTION The Dual-Link DVI splitter allows a single DVI-D signal to be split into two/four DVI outputs. Accept both Single-Link and Dual-Link DVI signal with supporting the highest resolution of WQXGA for Dual-Link and WUXGA@RB for Single-Link DVI this wonderful device allows users with a multi-screen viewing. -
Page 7: Operation Controls And Functions
EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel Dual-Link DVI OUT1: This slot is to connect with DVI output display with DVI cable for synchronize outputs up to 2/4. Dual-Link DVI IN: This slot is to connect with the input source such as PC/Graphic card with Dual-Link DVI cable. -
Page 8: Connection Diagram
EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter 7. CONNECTION DIAGRAM... -
Page 9: Specifications
EGE-DVI-142DL-144DL 1×2-1×4 Dual-link DVI Splitter 8. SPECIFICATIONS 2 x 165MHz Video Bandwidth 1 x Dual-Link DVI Input Port 2 or 4 x Dual-Link DVI Output Ports VGA ~ WQXGA@60 / Dual-Link I/O Support Resolution VGA~ WUXGA@60RB / SINGLE-LINK Human-body Model: ±8 kV (Air-gap discharge) - Page 11 www.geratech.eu...
