- Page 1 ® EGE-12VS 1×2 HDMI 4K2K Video Scaler...
- Page 2 EGE-12VS 1×2 HDMI 4K2K Video Scaler...
- Page 3 Geratech also makes no commitment to update or to keep current the information contained in this document. Geratech reserves the right to make improvements to this document and/or product at any time and without notice. COPYRIGHT NOTICE No part of this document may be reproduced,...
- Page 4 EGE-12VS 1×2 HDMI 4K2K Video Scaler SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-12VS 1×2 HDMI 4K2K Video Scaler CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 4. System Requirements ......5. Features ..........6. Hardware Description ......6.1 Front Panel .......... 2 6.2 Rear Panel ........ -
Page 6: Introduction
EGE-12VS 1×2 HDMI 4K2K Video Scaler 1. INTRODUCTION The 1 by 2 HDMI Scaler is designed to scale both 4K2K and non -4K2K HDMI signal into 1080p and also, bypass 4K2K signal out on to 4K2K display. Allowing all types of HDMI source signal to be display on HDTV/ Monitor. -
Page 7: Hardware Description
EGE-12VS 1×2 HDMI 4K2K Video Scaler 6. HARDWARE DESCRIPTION The following sections describe the hardware components of the unit. 6.1 Front Panel HDMI OUT HDMI IN DC 5V SERVICE SCALER BYPASS HDMI OUT/SCALER: This slot is to connect with HDMI TV/display for output AV displaying with resolution up to 1080p. -
Page 8: Rear Panel
EGE-12VS 1×2 HDMI 4K2K Video Scaler 6.2 Rear Panel geratech SERVICE RS- 232 EGE-12VS BYPASS POWER MENU ENTER 4K2K 720p RS- 232: This slot is reserve for factory use only. SERVICE 1: This slot is reserve for factory use only. -
Page 9: Osd Menu
EGE-12VS 1×2 HDMI 4K2K Video Scaler 6.3 OSD MENU Layer Layer Layer Layer Contrast 0~100 Brightness 0~100 0~100 Saturation 0~100 Sharpness 0~100 FineTune High/ Picture Middle/ Setting Exit 0~100 Green 0~100 Color Blue 0~100 Exit Output Full/Over Scan/Under Scan/Letter Size... - Page 10 EGE-12VS 1×2 HDMI 4K2K Video Scaler TimerOut 5~100 Background 0~100 Display Info/On/O Exit Factory Reset No/Yes Setting Exit Information Input …x… Output …x… Version x.xx Exit www.geratech.com.tr...
-
Page 11: Connection Diagram
EGE-12VS 1×2 HDMI 4K2K Video Scaler 7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI OUT HDMI IN DC 5V SERVICE SCALER BYPASS HD TV HD TV www.geratech.com.tr... -
Page 12: Speci Cations
EGE-12VS 1×2 HDMI 4K2K Video Scaler 8. SPECIFICATIONS Video Frequency 300MHz/9Gbps Input Ports 1 x HDMI, 2 x USB (Service only), 1 x RS -232 (Service only) Output Ports 2 x HDMI In 15M, Out 15M@1080p/8bit, In 10M, Out HDMI Cable Distance 10M@1080p/12bit, In 5M, Out 10M@4K2K 5V / 2.6A DC (US/EU standards, CE/FCC/... - Page 13 EGE-12VS 1×2 HDMI 4K2K Video Scaler HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x480i@60 720x576i@50 720x576p@50 800x600@56 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75 1280x720@60 1280x720p@60 1280x800@60 1280x1024@60 1440x1050@60 1600x1200@60 1920x1080@60 1920x1080i@50 1920x1080i@60 1920x1080p@23.97 1920x1080p@24 1920x1080p@25 1920x1080p@29.97 1920x1080p@30 1920x1080p@50...
- Page 14 EGE-12VS 1×2 HDMI 4K2K Video Scaler 1920x1080p@60 1920x1200@60(RB) www.geratech.com.tr...
- Page 15 www.geratech.com.tr...
