- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Cart and Stand Clamp Head Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MAC720...
-
Page 2: Installation Instructions
MAC720 Installation Instructions DISCLAIMER WARNING: Failure to read, thoroughly understand, and CSAV, Inc., and its affiliated corporations and subsidiaries follow all instructions can result in serious personal injury, (collectively, "CSAV"), intend to make this manual accurate and damage to equipment, or voiding of factory warranty! It is the complete. - Page 3 Installation Instructions MAC720 TOOLS REQUIRED FOR INSTALLATION AND PARTS 3/16" (Provided) C (1) A (1) B (1) E (2) D (4) F (1) (5/16-18 x 3/4") 3/16" H (2) (3/8-16 x 1") G (2) (3/8-16)
-
Page 4: Assembly And Installation
Assembly for Dual Display WARNING: TIPPING HAZARD! Place MAC720 only on FRONT of MFC and MF1. MAC720 may be placed on both FRONT and BACK of MF2. Attach first faceplate (A) to bracket (B) using two 3/8-16 x 1" roundhead carriage bolts (H), two spacers (E), and two 3/8-16 Nylock lock nuts (G). -
Page 5: Attaching Display(S)
WARNING: IMPROPER INSTALLATION CAN LEAD TO (D) x 4 CART/STAND OR DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! MAC720 must be Ensure mounting buttons are completely engaged in installed BELOW mounting holes. the knob located on the post back. - Page 6 F +31 (0) 40 2668615 Asia Pacific A Room 30I, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA. Post Code: 518112 8814-000006 2007 Chief Manufacturing www.chiefmfg.com P +86-755-8996 9226 ; 8996 9236 ; 8996 9220 07/07 F +86-755-8996 9217...
