Summary of Contents for CHIEF MAC790
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Medium Swivel Accessory for Carts and Stands MAC790...
- Page 2 Chief® and ClickConnect™ are registered trademarks of Reinforce the structure as required before installing the Milestone AV Technologies. All rights reserved.
- Page 3 Installation Instructions MAC790 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
- Page 4 Installation Instructions MAC790 TOOLS REQUIRED FOR INSTALLATION 3/16" (included) PARTS B(4) 5/16-18 x 5/8" C(1) A (1 3/16" [swivel accessory]...
- Page 5 Installation Instructions MAC790 ASSEMBLY Attaching Head to Cart/Stand Assembly CAUTION: ALWAYS remove the display(s) BEFORE adjusting the height of the cart/stand. IMPORTANT ! : When attaching head assembly ensure that the ClickConnect lock is at TOP of head assembly. Attach PSBU or MSBU interface bracket(s) to the display(s) following the instructions included with the bracket.
- Page 6 MAC790 Installation Instructions recommended that a bolt (not provided) be placed through the head assembly (See Figure 4) to lock the display into the upright position. Swivelling Display The display can be swivelled up to 15° either left or right from a Remove pin straight upright position.
- Page 7 Installation Instructions MAC790 Remove bolt or padlock if used Pin in "Closed" position - move to "Open" position to remove display Pin in "Open" position - move to "Closed" position after display is removed. Figure 6...
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Room 24F, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA.
