I N S T A L L A T I O N I N S T R U C T I O N S
Dual Ceiling Mount
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
MCD Series

Advertisement

Table of Contents
loading

Summary of Contents for CHIEF MCD Series

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Dual Ceiling Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MCD Series...
  • Page 2: Installation Instructions

    IMPORTANT ! : The MCD Series mounts are designed to be mounted to a 1-1/2" NPT or NPSM following ANSI/ASME Chief® and ClickConnect™ are registered trademarks of B1.20.1 (Schedule 40, 0.154"...
  • Page 3: Dimensions: Inches

    Installation Instructions MCD Series DIMENSIONS NOTE: MSBU/MSBV INTERFACE BRACKET 1-1/2" NPSM NOT SHOWN. THE MSBU/MSBV INTERFACE BRACKET NEEDED FOR YOUR DISPLAY WILL ADD DEPTH AND MAY AFFECT LOCATION OF DISPLAY ON THE MOUNT. 8.02 4.01 TOP MOUNTING BUTTON ON MSBU/MSBV BRACKET GOES HERE 1.01...
  • Page 4: Tools Required For Installation

    MCD Series Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" (Included) 9/16" PARTS B (1) 5/16-18 x 3/8" C (1) 5/32" A (1) [MCD Mount]...
  • Page 5: Installation

    Installation Instructions MCD Series INSTALLATION WARNING: FAILURE TO PROVIDE ADEQUATE STRUCTURAL STRENGTH FOR THIS COMPONENT CAN RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to make sure the structure to which this component is attached can support five times the combined weight of all equipment.
  • Page 6: Adjusting Display

    MCD Series Installation Instructions WARNING: Remove bolt IMPROPER INSTALLATION CAN LEAD TO or padlock DISPLAY FALLING CAUSING SERIOUS PERSONAL if used INJURY OR DAMAGE TO EQUIPMENT! Ensure mounting buttons are completely engaged in mounting holes. Holes are provided in the faceplate for use with a padlock or similar locking device, if desired.
  • Page 7 Installation Instructions MCD Series Adjusting Roll Loosen the Nylock roll adjustment nut on back of mounting plate. (See Figure 6) Tilt the faceplate left or right as required. Tighten nut. NOTE: Do NOT over tighten fasteners. Adjusting Pitch Adjust display to the desired pitch.
  • Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
