CHIEF JWDIW Specifications

In-wall mounts
maC501
26–40" lCds
2
1
WHAT YOU NEED TO KNOW
oRdeRIng InFoRmatIon
MAC501 and JWDIW must be ordered separately. Available in Universal
or Custom:
• Universal: Order MAC501 and JWDIW210B
Compatible with VESA 100 x 100 mm and 200 x 200 mm. Also includes
200 x 400 mm interface.
• CUstom: Order MAC501, JWDIW210B + MSB-xxxx
See MountFinder PRO on www.chiefmfg.com for custom MSB
™
model numbers.
RECOMMENDED ACCESSORIES
PaCPC1
For a complete list of flat panel mount accessories see page 73.
CliCk
42
www.chiefmfg.com
& JwdIw
™
4
Power Filter
n
In-Wall box & SWIng arm
™
3
1
2
3
4
Roll
Tilt
Swivel*
Extension
Box Dimensions
(HxWxD)
Color
Weight Capacity
* With 30" flat panel. Swivel range varies with screen size.
TECHNICAL DRAWINGS
14.5"
(368 mm)
14.5"
(368 mm)
CAll
800.582.6480
FEATURES
Low ProfiLe
Designed to ensure mount remains concealed
behind the screen.
Centris fingertiP tiLt
™
PatenteD FeatUre
Provides smooth fingertip tilt in all directions
using the screen's center of gravity. Screen
angle stays set until you decide to re-adjust.
easy instaLLation
Center flat panel at any position on wall
between 16" center studs without cutting
studs. no header/footer necessary!
smooth extension
extends 21.2" (538 mm) to achieve ideal
viewing angle.
SPECIFICATIONS
+/-5˚
±15˚
90˚ Left/Right
21.2" (538 mm)
14.5" x 14.5" x 4.2"
(368 x 368 x 107 mm)
Black
75 lbs (34 kg)
4.2"
(107 mm)
retracted
5"
(127 mm)
9.88"
(251 mm)
