- Page 1 Davies Dual Base Ottoman Bed with O.S.B Single Size Section A: Metal Slat-Frame Version Section B: Mattress Base Board Version From Page 15 to Page 27 From Page 5 to Page 14 Opening on the left Opening on the right 1.5 hour approx...
- Page 2 Before removing the mattress secure the frame to ensure it does not open unexpectedly. Do not attempt to lie on the mattress when the ottoman is in the raised postion. When lifting the ottoman, remove all bedding except the fitted sheet. Davies Ottoman Bed - Assembly guide - Page 2...
- Page 3 Do not sit on the mattress whilst the platform is in motion or is in the raised position. o Users should only get in and out of bed when platform is in the flat (horizontal) position. Davies Ottoman Bed - Assembly guide - Page 3...
-
Page 4: Assembly Tips
Thank you Hello, thanks for choosing to purchase your bed from Dreams - you're now on your way to your best ever night's sleep. Before you begin building your bed, please take a moment to read through the instructions and make sure that you've got all the relevant parts listed on the following pages. -
Page 5: Section A: Metal Slat-Frame Version
Side Rails Fixed retaining bracket Side Rail Cross Bar Parking bracket Ea & Eb. Gas Lift Mechanisms 1 Pair Metal Slat Frame Angled Brackets Gas Lift Pistons Fabric Base Cover Mattress Stopper Davies Ottoman Bed - Assembly guide - Page 5... -
Page 6: Tools Required
Flanged lock-nuts (M8) for gas-lift pistons Spanner for M8 nuts Nuts for M8 slat frame bolts (e) Tools required Tape measure Cross head screwdriver 0 10 1 Davies Ottoman Bed - Assembly guide - Page 6... - Page 7 Bolt into the holes marked (R) with blue labels. The mechanisms are labeled E(a) & E(b). Please carefully follow the diagram below. Align with the Blue labels Bolts should be in centre of long holes Davies Ottoman Bed - Assembly guide - Page 7...
- Page 8 Bolt into the holes marked (L) with red labels. The mechanisms are labeled E(a) & E(b) please carefully follow the diagram below. Align with the Red labels Bolts should be in centre of long holes Davies Ottoman Bed - Assembly guide - Page 8...
- Page 9 Hardware pre-fitted to the Assemble the bed Headboard & Footboard (A&B) Please do not remove these screws - unscrew them by 10mm Bolts (M8x30mm) using Allen key (4) & 100% Davies Ottoman Bed - Assembly guide - Page 9...
- Page 10 Lift up the support bars and fit the slat-frame positioning the frame so the gap around the edges is equal, then then tighten all nuts & bolts 100%. Bolt into centre of long holes Davies Ottoman Bed - Assembly guide - Page 10...
- Page 11 Fit the mattress stoppers to the slat-frame. Fit the gas-lift pistons to the mechanisms. SMALL GAP Davies Ottoman Bed - Assembly guide - Page 11...
- Page 12 Unpack the contents of the Ottoman Support Bar (O.S.B.) from it's carton - this is packed inside Pack 2. c x2 b x2 m x2 Davies Ottoman Bed - Assembly guide - Page 12...
- Page 13 Setting the inner stem of the support bar (H), adjust the inner stem to the correct length. Parking position Davies Ottoman Bed - Assembly guide - Page 13...
- Page 14 Maximum storage height is 275mm . WARNING! HAZARD - DO NOT REACH INTO THE SPACE BELOW! Davies Ottoman Bed - Assembly guide - Page 14...
-
Page 15: Section B: Mattress Base Board Version
S ide Rail Cross Bar P arking bracket Ea & Eb. Gas Lift Mechanisms 1 Pair M attress Base Board A ngled Corner Brackets G as Lift Pistons M attress Stoppers F abric Base Cover Davies Ottoman Bed - Assembly guide - Page 15... - Page 16 Big Head Bolts (M8x20mm) for fitting metal plate (q) and Metal Plate for Fabric mattress stoppers (S) Hand Strap Tools required Tape measure Cross head screwdriver 0 10 1 Davies Ottoman Bed - Assembly guide - Page 16...
- Page 17 Bolt into the holes marked (R) with blue labels. The mechanisms are labeled E(a) & E(b). Please carefully follow the diagram below. Align with the Blue labels Bolts should be in centre of long holes Davies Ottoman Bed - Assembly guide - Page 17...
- Page 18 Bolt into the holes marked (L) with red labels. The mechanisms are labeled E(a) & E(b) please carefully follow the diagram below. Align with the Red labels Bolts should be in centre of long holes Davies Ottoman Bed - Assembly guide - Page 18...
- Page 19 Hardware pre-fitted to the Assemble the bed Headboard & Footboard (A&B) Please do not remove these screws - unscrew them by 10mm Bolts (M8x30mm) using Allen key (4) & 100% Davies Ottoman Bed - Assembly guide - Page 19...
- Page 20 Loosely fit both piston stems to the axles Please make sure the cylinder (largest diameter) is at the top. Upper End SMALL GAP Lower End Prepare the lower mattress base board (P). 15mm Davies Ottoman Bed - Assembly guide - Page 20...
- Page 21 Fit the mattress base board (P) at the bottom of the support arms .. iii. Davies Ottoman Bed - Assembly guide - Page 21...
- Page 22 Allen key (d). Unpack the contents of the Ottoman Support Bar (O.S.B.) from it's carton - this is packed inside Pack 2. 100% c x2 100% b x2 m x2 Davies Ottoman Bed - Assembly guide - Page 22...
- Page 23 Set the inner stem to the correct length so the end just touches the retaining bracket - it needs to touch to hold it in position. 100% Adjust the retaining bracket (J) so the stem end scrapes the surface. Davies Ottoman Bed - Assembly guide - Page 23...
- Page 24 With the bed in it's final location, fit the fabric base cover (G) evenly around the inside of the bed. Carefully fit the side rail support bar taking care not to damage the fabric. p x2 c x2 b x2 a x2 Davies Ottoman Bed - Assembly guide - Page 24...
- Page 25 Regularty base is open. secure when the air internal storage area and contents. Regularty air internal storage area and contents. WARNING! HAZARD - DO NOT REACH INTO THE SPACE BELOW! Davies Ottoman Bed - Assembly guide - Page 25...
-
Page 26: Care And Maintenance
Metal tends to be more resilient to everyday wear and tear. We recommend to gently dust your metal furniture and keep it dry to maintain its look. Thank you for shopping with us - we hope you have a great night's sleep - Care and maintenance - Page 26 Davies Ottoman Bed... - Page 27 Little dreamers Keep the little ones entertained while you assemble your new purchase.
