- Page 1 UC-8410A Series Quick Installation Guide Version 3.3, November 2023 Technical Support Contact Information www.moxa.com/support 2023 Moxa Inc. All rights reserved. P/N: 1802084100016 *1802084100016*...
-
Page 2: Package Checklist
Overview The UC-8410A Series of dual-core embedded computers support a rich variety of communication interfaces and come with 8 RS-232/422/485 serial ports, 3 Ethernet ports, 1 PCIe mini slot for a wireless module (not for the -NW model), 4 digital input channels, 4 digital output channels, 1 SD card slot, 1 mSATA socket, and 2 USB 2.0 hosts. - Page 3 Rear View Left-side View Installing the UC-8410A Wall or Cabinet The two metal brackets included with the UC-8410A can be used to attach it to a wall or the inside of a cabinet. Using two screws per bracket, first attach the brackets to the bottom of the UC-8410A. These four screws are included in the wall-mounting kit.
- Page 4 Head Type: round or pan These four screws are not included in the wall-mounting kit and must be Head Diameter: > 4.5 mm Length: > 4 mm purchased separately. Refer to the Thread Size: M3 x 0.5 mm detailed specifications on the right. DIN Rail The UC-8410A comes with a DIN-rail mounting kit, which includes a black plate, a silver DIN-rail mounting plate, and six screws.
- Page 5 Refer to the figure on the right for the screw specifications. To install the computer on a DIN-rail, follow these steps: Step 1—Insert the upper lip of the DIN-rail kit into the mounting rail. Step 2—Press the UC-8410A computer towards the mounting rail until it snaps into place.
-
Page 6: Connector Description
Connector Description Connecting the Power Connect the 12-48 VDC power line to the UC-8410A’s terminal block. The Ready LED will glow a steady green color after 30 to 60 seconds have passed. ATTENTION The product is intended to be supplied by a UL Listed power supply suitable for use at Tma = 75°C whose output meets ES1 and PS2/LPS rated 12 to 48 VDC, 1.57 A (min), or 24 VDC, 0.78 A (min). - Page 7 Serial Ports The 8 serial ports (P1 to P8) use RJ45 connectors. Each port can be configured by software as RS-232, RS-422, or RS-485. The pin assignments are shown in the following table: RS-422/ RS-232 RS-485 RS-485-4W – – TXD+ –...
-
Page 8: Reset Button
2. Remove the cover to access the SD-card slot and the mSATA socket. 3. Push the SD card in gently to release it and remove the SD card to insert a new one in the socket. Make sure your SD card has been securely inserted. -
Page 9: Real-Time Clock
Real-time Clock The real-time clock is powered by a lithium battery. We strongly recommend that you do not replace the lithium battery without the help of a Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team. ATTENTION There is a risk of explosion if the battery is replaced with an incorrect type of battery. - Page 10 Powering on the UC-8410A Computer To power on the UC-8410A, connect a terminal block to power jack converter to the UC-8410A’s DC terminal block (located on the left rear panel), and then connect the power adapter. Note that the Shielded Ground wire should be connected to the right most pin of the terminal block.
-
Page 11: Configuring The Ethernet Interface
After the boot settings of the LAN interface have been modified, use the following command to activate the LAN settings with immediate effect: #sync; ifup –a NOTE Refer to the UC-8410A Series Linux Software User’s Manual for additional configuration information. - 11 -...
