Moxa Technologies UC-4400A Series Quick Installation Manual
Moxa Technologies UC-4400A Series Quick Installation Manual

Moxa Technologies UC-4400A Series Quick Installation Manual

Hide thumbs Also See for UC-4400A Series:

Advertisement

Quick Links

UC-4400A Series
Quick Installation Guide
Version 1.0, September 2024
Technical Support Contact Information
www.moxa.com/support
 2024 Moxa Inc. All rights reserved.
P/N: 1802044000001
*1802044000001*

Advertisement

loading
Need help?

Need help?

Do you have a question about the UC-4400A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moxa Technologies UC-4400A Series

  • Page 1 UC-4400A Series Quick Installation Guide Version 1.0, September 2024 Technical Support Contact Information www.moxa.com/support  2024 Moxa Inc. All rights reserved. P/N: 1802044000001 *1802044000001*...
  • Page 2 RS-232/422/485 serial ports and dual 10/100/1000 Mbps Ethernet LAN ports, as well as M.2 and Mini PCIe sockets to support cellular and Wi-Fi modules. These versatile communication capabilities let users efficiently adapt the UC-4400A Series to a variety of complex communications solutions. Package Checklist...
  • Page 3 Panel Layouts The panel layouts of the UC-4400A models are given below: UC-4410A UC-4414A NOTE The P4 and P5 serial ports come with built-in 2 kV isolation. - 3 -...
  • Page 4 UC-4430A UC-4434A NOTE The P4 and P5 serial ports come with built-in 2kV isolation. UC-4450A - 4 -...
  • Page 5 UC-4454A LED Indicators LED Name Status Function Green Power is on PWR1/PWR2 No power Steady on: The device has successfully booted and all services are initialized Green Blinking: Device is in the process of booting up READY Device boot failure, which occurs if any service fails to initialize The device remains in the bootloader stage and has not yet booted into the...
  • Page 6 Mounting the UC-4400A Series The UC-4400A Series can be mounted on to a DIN rail or on to a wall. The DIN-rail mounting kit is attached to the computer by default. To order a wall-mounting kit, contact a Moxa sales representative.
  • Page 7 DIN-rail Mounting The aluminum DIN-rail attachment plate is attached to the product’s casing. To mount the UC-4400A Series on to a DIN rail, ensure that the stiff metal spring is facing upwards and follow these steps. 1. Pull down the slider of the DIN-rail bracket located at the back of the unit.
  • Page 8 To mount the computer on to a wall, do the following: Step 1 Step 2 Use the four screws (M3 x 5 mm) in Use another four screws (M3 x 6 the package to fasten the wall- mm) to mount the computer on to mounting brackets to the computer.
  • Page 9 ATTENTION The wiring for the input terminal block should be installed by a skilled person. The wire type should be copper (Cu), wire size should be 14 AWG to 16 AWG (2.08 to 1.31 mm²), and a torque of 0.19 n-m should be used for V+, V-, and GND connections.
  • Page 10 Grounding the Computer There is a grounding connector located on the top panel of the computer. Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Note that this product is intended to be mounted on a well-grounded mounting surface, such as a metal panel.
  • Page 11 RS-422/ RS-232 RS-485 2w RS-485 4w TxD-(A) – TxD+(B) – RxD+(B) Data+(B) RxD-(A) Data-(A) – – – – – – CAN Ports One or two (P3, P6) CAN ports with DB9 interfaces are located on the bottom panel. The pin assignment is shown in the following table: Definition –...
  • Page 12 Step 1 Step 2 Remove the screw securing the The SIM card tray can hold two SIM SIM card holder cover on the cards, one on each side. front panel of the computer. Install the first SIM card in the SIM1 slot and the second SIM card on the opposite side of the tray.
  • Page 13 All cellular and GPS connectors are of type SMA female. Real-time Clock The real-time clock in the UC-4400A Series is powered by a lithium battery. We strongly recommend that you do not replace the lithium battery without the help of a Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team.
  • Page 14 Accessing the UC-4400A Series Using a PC You can use a PC to access the UC-4400A Series by one of the following methods: Through the serial console port with the following settings: Baudrate=115200 bps, Parity=None, Data bits=8, Stop bits=1, Flow Control=None ATTENTION Remember to choose the VT100 terminal type.
  • Page 15 CE/UKCA Statement ATTENTION 1. The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range. 2. This device is intended for indoor use only when operating in the frequency range 5945 to 6425 MHz, which is applicable in countries that support Wi-Fi 6E.
  • Page 16 RCM Statement ATTENTION The frequency range of 5600 to 5650 MHz is not permitted for use in Australia. KC Statement 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. 상호: Moxa Inc. 기자재 명칭: Arm-based Platform 모델명: MXEG4400-2S1C, MXEG4400-2S1CNW, MXEG4400-4SI2C, MXEG4400-4SI2CNW 제조자...
  • Page 17 BSMI—限用物質含有情況標示聲明書 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 嵌入式平台 型號(型式): UC-4410A-T, UC-4414A-I-T Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominat Polybrominated Lead Mercury Cadmium...
  • Page 18 WARNING 警告:為避免電磁干擾,本產品不應安裝或使用於住宅環境。 警告:更換不正確之電池形式會有爆炸的風險,請依製造商說明書處理用 過之電池。 製造商:四零四科技股份有限公司 地址:桃園市八德區和平路 1111 號 服務電話:+886-3-273-7575 - 18 -...
