- Page 1 UC-4400A Series Hardware User’s Manual Version 1.0, October 2024 www.moxa.com/product © 2024 Moxa Inc. All rights reserved.
-
Page 2: Copyright Notice
UC-4400A Series Hardware User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2024 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc. -
Page 3: Table Of Contents
Table of Contents Introduction ............................1 Package Checklist ..........................2 Product Features ........................... 2 Product Specifications ..........................2 Hardware Introduction ......................... 1 Appearance ............................2 UC-4410A-T ..........................2 UC-4414A-I-T ..........................2 UC-4430A-I ........................... 3 UC-4434A-I-T ..........................3 UC-4450A-T-5G ..........................4 UC-4454A-T-5G .......................... -
Page 4: Introduction
Introduction The UC-4400A Series computing platform is designed for embedded data acquisition applications. The UC- 4400A computers come with two or four RS-232/422/485 serial ports and dual 10/100/1000 Mbps Ethernet LAN ports, as well as M.2 and Mini PCIe sockets to support cellular and Wi-Fi modules. These versatile communication capabilities let users efficiently adapt the UC-4400A Series to a variety of complex communications solutions. -
Page 5: Package Checklist
UC-4400A Series HW UM Introduction Package Checklist Before installing a UC-4400A computer, verify that the package contains the following items: • 1 x UC-4400A Series embedded computer • 1 x Quick installation guide (printed) • 1 x Warranty card (printed) NOTE Notify your sales representative if any of the above items are missing or damaged. -
Page 6: Hardware Introduction
The LED indicators allow you to monitor device performance and quickly identify issues, and the multiple ports can be used to connect a variety of devices. The UC-4400A Series comes with a reliable and stable hardware platform that lets you devote the bulk of your time to application development. In this chapter, we provide basic information about the embedded computer’s hardware and its various... -
Page 7: Appearance
UC-4400A Series HW UM Hardware Introduction Appearance UC-4410A-T UC-4414A-I-T NOTE P4 and P5 serial ports come with built-in 2kV isolation. -
Page 8: Uc-4430A-I
UC-4400A Series HW UM Hardware Introduction UC-4430A-I UC-4434A-I-T NOTE P4 and P5 serial ports come with built-in 2kV isolation. -
Page 9: Uc-4450A-T-5G
UC-4400A Series HW UM Hardware Introduction UC-4450A-T-5G UC-4454A-T-5G... -
Page 10: Dimensions
UC-4400A Series HW UM Hardware Introduction Dimensions UC-4410A-T UC-4414A-I-T... -
Page 11: Uc-4430A-T
UC-4400A Series HW UM Hardware Introduction UC-4430A-T UC-4434A-I-T... -
Page 12: Uc-4450A-T-5G
UC-4400A Series HW UM Hardware Introduction UC-4450A-T-5G UC-4454A-T-5G... -
Page 13: Led Indicators
UC-4400A Series HW UM Hardware Introduction LED Indicators The function of each LED is described in the table below: LED Name Status Function Green Power is on PWR1/PWR2 No power Steady on: The device has successfully booted and all services are initialized... -
Page 14: Real-Time Clock
UC-4400A Series HW UM Hardware Introduction Real-time Clock The UC-4400A’s real time clock is powered by a non-chargeable battery. We strongly recommend that you do not replace the lithium battery without help from a qualified Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team. -
Page 15: Wall Mounting (Optional)
Hardware Introduction Wall Mounting (optional) The UC-4400A Series can be mounted on to a wall using a wall-mounting kit as shown in the following illustrations. The optional wall-mounting kit is not included in the product package and should be purchased separately. - Page 16 UC-4400A Series HW UM Hardware Introduction NOTE • Test the screw head and shank size by inserting the screws into one of the keyhole shaped apertures of the wall-mounting plates before attaching the plate to the wall. • • Do not drive the screws in all the way—leave a space of about 2 mm to allow room for sliding the wall mount panel between the wall and the screws.
-
Page 17: Hardware Connection Description
Hardware Connection Description In this chapter, we describe how to connect the UC-4400A to a network and various devices. The following topics are covered in this chapter: Wiring Requirements Connecting the Power Grounding the Unit Connecting the Network ... -
Page 18: Wiring Requirements
Connecting the Power Connect the power jack (in the package) to the UC-4400A Series’ DC terminal block (located on the top panel), and then connect the power adapter. It takes about 10 to 30 seconds for the system to boot up. -
Page 19: Grounding The Unit
UC-4400A Series HW UM Hardware Connection Description WARNING This product is intended to be supplied by a UL Listed Power Unit marked LPS (Limited Power Source). The ratings for the different models in the series are as follows: • UC-4410A and UC-4414A: 9 VDC (1.53 A min) to 48 VDC (0.21 A min) and Tma = 75°C (min) •... -
Page 20: Connecting A Usb Device
Connecting a USB Device The UC-4400A Series computers come with a USB port located at the lower part of the front panel, allowing users to connect to a device with a USB interface. The USB port uses a type A connector. By default, the USB storage is mounted at /mnt/usbstorage. -
Page 21: Connecting The Digital Inputs And Digital Outputs
UC-4400A Series HW UM Hardware Connection Description Connecting the Digital Inputs and Digital Outputs There are four digital inputs and four digital outputs on the top panel. Refer to the figure on the left for detailed pin definitions. Inserting the SIM Card The UC-4430A-T, UC-4434A-I-T, UC-4450A-T-5G, UC-4454A-T-5G computers come with a nano-SIM card slot that can install two SIM cards for cellular communication. -
Page 22: Connecting The Console Port
UC-4400A Series HW UM Hardware Connection Description Connecting the Console Port The console port is an RS-232 port located on the lower part of the front panel. To install the card, remove the screw and the protection cover to access the console port. You can connect a 4-pin pin header cable and use the port for debugging issues or system image upgrades. -
Page 23: Regulatory Approval Statements
Regulatory Approval Statements FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
