Saflok QuantumIII RFID
(Quantum Series)
Installation instructions
PK3663-T - 2019 - 09
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the Quantum Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Dormakaba Quantum Series

  • Page 1 Saflok QuantumIII RFID (Quantum Series) Installation instructions PK3663-T - 2019 - 09...
  • Page 2 Saflok QuantumIII Installation Instructions All parts needed to install the Saflok Quantum III lock are included with each unit. Please check to make sure all parts are accounted for before beginning installation. Do not substitute any of the parts. The use of substitute parts will result in poor performance of the lock.
  • Page 3 Preparing the door and door frame WARNING CAUTION Prepare the door using the Quantum III reader installation template or drill fixture. The door edge prep is a standard, full-mortise prep for a 1-1/4” x 8” front plate (1” x 8” and 1” x 7-3/4” custom front plates are optional).
  • Page 4 Preparing the door and door frame (continued) WARNING The mortise plate has an adjustable bevel. Align the mortise front plate with the bevel of the door edge and tighten the two bevel adjustment screws at the top and bottom of the mortise case. Position the mortise case in the door edge with the motor wire routed through the notch (see Fig.
  • Page 5 Installing the lock trim The outside lever trim has two carriage bolts that fit into the diagonal holes in the mortise case. These carriage bolts establish an accurate trim position with respect to the mortise case assembly, allowing the levers and bolt mechanism to operate without binding. The holes machined in the door surfaces should not influence the position of the trim or the card reader assembly.
  • Page 6 Installing the lock trim (continued) WARNING 8. Connect reader ribbon cable, reader power cable, motor cable, and power wire to the PCB. See Fig. 6. Be sure not to crease the ribbon. CAUTION Watch for the green LED on the card reader to flash once, and for the clutch motor to reset when you connect the battery wire to the PCB.
  • Page 7 Installing the lock trim (continued) 12. Secure the inside trim cover to the inside trim using two M4 x 16mm Torx screws (see Fig. 7). 13. Program the lock using the Lock Programmer and Interrogator (LPI) probe with the LPI-R device cable.
  • Page 8 Testing Lock Functionality Pass a construction key over the QuantumIV RFID reader. The green light will flash for five seconds. Be sure that the green light flashes for five seconds while the exterior lever remains operable. If the green lights do not flash, refer to the table below. Lock Communication Electronic Function Description Red and green LEDs flash...
  • Page 9 Door Unit Inspection Criteria Appearance • Finish is free of blemishes or scratches that would distract from lock appearance • Lock body and under plate (if used) are mounted straight on the door • Door scalp is mounted straight and flush with the door edge •...
  • Page 10 Customer Services & Support Ilco: 1.877.468.3555 / + 1.514.340.9025 Saflok: 1.800.999.6213 / + 1.248.837.3700 General Information: www.kabalodging.com Online Consumable Orders: www.ilcostore.com www.saflokstore.com To access all of our easy steps, please visit our Support Website: www.kabalodgingsupport.com www.dormakaba.com...
