Field Description
When creating a new GFS resource, you can leave this field blank. Leaving the
field blank causes a file system ID to be assigned automatically after you commit
the parameter during configuration. If you need to assign a file system ID explicitly,
specify it in this field.
Force If enabled, forces the file system to unmount. The default setting is disabled.
Unmount Force Unmount kills all processes using the mount point to free up the mount
when it tries to unmount. With GFS resources, the mount point is not unmounted at
service tear-down unless Force Unmount is enabled.
Reboot If enabled and unmounting the file system fails, the node will immediately reboot.
Host Node Generally, this is used in conjunction with force-unmount support, but it is not
if Unmount required.
Fails (self
fence)
Table C.4. GFS
Field Description
IP Address The IP address for the resource. This is a virtual IP address. IPv4 and IPv6
addresses are supported, as is NIC link monitoring for each IP address.
Monitor Link Enabling this causes the status check to fail if the link on the NIC to which this IP
address is bound is not present.
Table C.5. IP Address
Field Description
Name A unique name for this LVM resource.
Volume Group A descriptive name of the volume group being managed.
Name
Logical Name of the logical volume being managed. This parameter is optional if there is
Volume Name more than one logical volume in the volume group being managed.
(optional)
Table C.6. LVM
Field Description
Name Specifies a name of the MySQL server resource.
Config File Specifies the configuration file. The default value is /etc/my.cnf.
Listen Specifies an IP address for MySQL server. If an IP address is not provided, the first
Address IP address from the service is taken.
mysqld Other command line options for httpd.
Options
Shutdown Specifies the number of seconds to wait for correct end of service shutdown.
Wait
(seconds)
Table C.7. MySQL®
Field Description
Name This is a symbolic name of a client used to reference it in the resource tree. This is
not the same thing as the Target option.
