Chapter 3. Configuring Red Hat Cluster With Conga
8. Modifying failover domain membership — Under Failover domain membership, click the
Membercheckbox for each node that is to be a member of the failover domain. A checked box for
a node means that the node is a member of the failover domain. If Prioritized is checked, you can
adjust the priority in the Priority text box for each member of the failover domain.
9. Click Submit. Clicking Submit causes a progress page to be displayed followed by the display
of the Failover Domain Form page. That page displays the added resource and includes the
failover domain in the cluster menu to the left under Domain.
10. To make additional changes to the failover domain, continue modifications at the Failover Domain
Form page and click Submit when you are done.

3.8. Adding Cluster Resources

To add a cluster resource, follow the steps in this section. The starting point of the procedure is at
the cluster-specific page that you navigate to from Choose a cluster to administer displayed on the
cluster tab.
1. At the detailed menu for the cluster (below the clusters menu), click Resources. Clicking
Resources causes the display of resources in the center of the page and causes the display of
menu items for resource configuration: Add a Resource and Configure a Resource.
2. Click Add a Resource. Clicking Add a Resource causes the Add a Resource page to be
displayed.
3. At the Add a Resource page, click the drop-down box under Select a Resource Type and select
the type of resource to configure.
parameters.
4. Click Submit. Clicking Submit causes a progress page to be displayed followed by the display
of Resources forcluster name page. That page displays the added resource (and other
resources).

3.9. Adding a Cluster Service to the Cluster

To add a cluster service to the cluster, follow the steps in this section. The starting point of the
procedure is at the cluster-specific page that you navigate to from Choose a cluster to administer
displayed on the cluster tab.
1. At the detailed menu for the cluster (below the clusters menu), click Services. Clicking Services
causes the display of services in the center of the page and causes the display of menu items for
services configuration: Add a Service and Configure a Service.
2. Click Add a Service. Clicking Add a Service causes the Add a Service page to be displayed.
3. On the Add a Service page, at the Service name text box, type the name of the service.
Below the Service name text box is an checkbox labeled Automatically start this service.
The checkbox is checked by default. When the checkbox is checked, the service is started
automatically when a cluster is started and running. If the checkbox is not checked, the service
must be started manually any time the cluster comes up from the stopped state.
38
Appendix C, HA Resource Parameters
describes resource
