Chapter 5. Configuring Red Hat Cluster With system-config-cluster
1. On the Resources property of the Cluster Configuration Tool, click the Create a Resource
button. Clicking the Create a Resource button causes the Resource Configuration dialog box to
be displayed.
2. At the Resource Configuration dialog box, under Select a Resource Type, click the drop-down
box. At the drop-down box, select a resource to configure.
describes resource parameters.
3. When finished, click OK.
4. Choose File => Save to save the change to the /etc/cluster/cluster.conf configuration
file.

5.8. Adding a Cluster Service to the Cluster

To add a cluster service to the cluster, follow these steps:
1. At the left frame, click Services.
2. At the bottom of the right frame (labeled Properties), click the Create a Service button. Clicking
Create a Service causes the Add a Service dialog box to be displayed.
3. At the Add a Service dialog box, type the name of the service in the Name text box and click OK.
Clicking OK causes the Service Management dialog box to be displayed (refer to
"Adding a Cluster Service").
Note
Use a descriptive name that clearly distinguishes the service from other services in
the cluster.
64
Appendix C, HA Resource Parameters
Figure 5.9,
